Karma Flexx HD - Seat Height Adjustment (22;24 Wheels)

38
5.3.2 Seat Height Adjustment for 22" and 24" Rear Wheels
Caster Position
Rear Wheel Position
Anti-Tipper Position
(For 457 ㎜(18")~533 ㎜
(21") seat height)
Seat
Height
Caster Size
Caster Position
Rear
Wheel
Caster
Bracket
Rear
Wheel
Position
Seat
Angle
Anti-Tipp
er
Position
533 ㎜
(21")
8"
24"
6
6.6〫
1-4
11
6.1〫
16
5.7〫
502 ㎜
(20")
7"
8"
24"
7
6.5〫
1-3
12
6.1〫
17
5.8〫
7"
8"
22"
6
5.8〫
11
5.6〫
16
5.4〫
483 ㎜
(19")
7"
6"
24"
8
5.4〫
1-2
13
5.2〫
18
5.0〫
7"
6"
22"
7
4.6〫
12
4.3〫
17
4.1〫
457 ㎜
(18")
6"
22"
8
7.1〫
1-1
13
6.7〫
18
6.3〫
