Karma KP-31 User Manual

35
Figure 6-12
Figure 6-13
Figure 6-14
Figure 6-15
6.6.2.3 Re-tighten the screws on the partition plate (before the screws are
tightened, adjust the strap first to so that the remaining end of the
strap is not protruding out of the battery box). (Figure 6-14)
Figure 6-16
Figure 6-17
6.6.2.4 Fixate the wires and the batteries by pulling firmly on the battery
strap. Fasten the strap firmly. (Figure 6-15)
6.6.2.5 Plug in the lighting connectors. Connect the left turn signal with the
wire marked with [LEFT], and connect the right turn signal with the
wire marked with [RIGHT]. (Figure 6-16)
6.6.2.6 Re-tighten the screws on the rear cover. (Figure 6-17)
WARNING
● There are many risks involved with improper disposal of batteries,
whether damaged or not. Batteries may contain heavy metals and be
considered hazardous waste.
● Many regions around the world now strictly enforce laws to help
protect our environment. By not disposing of batteries properly, you
may be liable for fines from your local through national government.
● By not recycling batteries, they end up in landfills where lead and other
chemicals may leach into streams and rivers destroying ecosystems and
poisoning local water resources.
● Improper disposal of batteries may also cause injury to unsuspecting
others that come in contact with them. If you come in contact with
fluids or corroded powder from a battery, rinse with water and contact
