11
3.5 S-Ergo 115 with 14〞 Rear Wheel Parts Description (Swing-away
footrest)
1. Push Handle
2. Armrest
3. Side Panel
4. Brake
5. Footrest
6. Calf Strap
7. Backrest Upholstery
8. Attendant Brake
9. Seat Upholstery
10. Cross Frame (Cross bar)
11. Rear Wheels
12. Caster
13. Footplate
