Karma S-Ergo 100 Series User Manual

14
4. OPERATION
4.1 Preparing For Use
4.1.1 Unfolding
4.1.1.1 Hold the grip and fold up the back joint, and you will hear a sound. (See
Figure 4.1.)
4.1.1.2 Hold the armrests and pull outwards. (See Figure 4.2.)
4.1.1.3 Point your fingers inward with the palm of your hand on the frame, push it
down until the seat is fully lowered. Make sure the frame is firmly seated
in its holder. (See Figure 4.3.)
4.1.1.4 Push down the joint of the rigidifying push-bar, and you can hear a sound.
(For S-106, see Figure 4.4.)
4.1.1.5 Flip the footplates down. (See Figure 4.5.)
4.1.1.6 Ready to use! (See Figure 4.6.)
Alternatively, you can stand at the side of the wheelchair and complete step 1 by
pulling the nearest armrest towards yourself and pushing the other one away.
Figure 4.1
Figure 4.2
Figure 4.3
Figure 4.4
Figure 4.5
Figure 4.6
