LS30 CONTROLLER INSTALLATION AND OPERATING GUIDE
11
3.4 Digital Input Connecons
Please ask for digital input connecons.
3.5 Relay Output Connecons
Pump, solenoid valve or siren type of coiled and high current
consumpon devices that will be controlled with relay outputs
should be denitely controlled by auxiliary relay or contactor
indirectly. In contrary relay contacts may damage or by scking
and by making nozzle may cause operaon of any device that
should not operate and therefore the system can be severally
damaged (for example overspill of depot).
Note: It has been drawn by considering that all of equipments of con-
necon schemac are operang with 220 VAC power. According to dif-
ferent power values connecon way may vary.
L N
RELAY
(or CONTACTOR)
LOAD
3 - 6A
220 VAC
12 11
10 9 8
7
3
2 1
L N 21
20 19 15
14
1318
17
16
RELAY INPUT
(R2)
RELAY INPUT
(R3)
RELAY INPUT
(R1)
(Fuse
According
to General
Load)
