Kaysun KPC-52 DR13 - Unit Parts

Unit Parts
NOTE ON ILLUSTRATIONS
Illustrations in this manual are for explanatory purposes. The actual shape of your indoor
unit may be slightly dierent. The actual shape shall prevail.
NOTE: The installation must be performed in accordance with the requirement of local and
national standards. The installation may be slightly dierent in dierent areas.
Unit Parts
Display panel
Drain pipe
Installation part
Connecting pipe
Air inlet
Air outlet
Remote controller
Air ow louver (at air outlet)
Air inlet (with air lter in it)
1
24
3
6
7
8
8
9
5
1
2
3
4
5
6
7
8
9
 Page 19

