11
FIGURE 2 B MECHANICAL SPECIFICATIONS (Inches / [mm])
M1L1 L2 M2
F+ F-
6.50
[165]
[178]
7.00
3.50
[5.08]
0.20
0.625
[15.9]
[88.9]
[6.35]
0.25
[120]
4.75
MAXIMUM HEIGHTS
Without Accessory Boards
1.70
[43.2]
With Accessory Boards
3.10
[78.7]
