KE2 LowTemp
Quick Start Guide
KE2 LowTemp
Quick Start Guide
Q.3.29 (Q.1.29) May 2017
Page 15
Controller Navigation - Menu Structure
Access Setpoint mode by pressing and holding the button until
tS (temperature setpoint) displays on the screen
ENTER
Use the up and down arrows to scroll through the available setpoints.
ENTER
Press to view the current setting.
Indicator lights
Red light - Basic Menu - not used; Advanced Menu - pulsing
Yellow light - non-critical alarm (system running)
Green light - compressor on
Green ashing - compressor waiting on timer to start/stop
Use the up and to change the setpoint
ENTER
Press to move between the digits to accelerate the changes.
ENTER
Press and hold to conrm each setpoint change
BACK
Press to escape.
.
tS
diF
CSH
dtyP
dPd
Only visible if CUS
(custom) is selected for
dPd (Defrost per day)
tOd
d1
d2
d3
d4
d5
d6
d7
d8
d9
d10
d11
d12
dtsP
dFt
drnt
Fndf
HAO
LAO
tAd
ADVANCED MENU
tS
diF
CSH
FrEF
AU1
StA1
AU2
StA2
tS2
dtyP
dPd
Only visible if CUS
(custom) is selected for
dPd (Defrost per day)
tOd
d1
d2
d3
d4
d5
d6
d7
d8
d9
d10
d11
d12
dtSP
dFt
drnt
FdSP
Fndt
FndF
Pdt
HAO
LAO
tAd
Adr
Unt
Accessing the Menus
Press and hold
for 3 seconds
BASIC MENU
Press and hold
for 3 seconds
rtP
Clt
One of the follwing is visible ONLY
if 1st Auxiliary input (AU1) is used
trdF or
indF or
dFLo or
dFin or
t2nd or
dOOr or
SYOF or
COiL or
rtP
One of the follwing is visible ONLY
if 2nd Auxiliary input (AU2) is used
trdF or
indF or
dFLo or
dFin or
t2nd or
dOOr or
SYOF or
COiL or
rtP
SySt
CPrl
dFrl
Fnrl
ALSt
Default menu -
Non Adustable (view only)
VARIABLES MENU
