Terminal strip X3 (lower terminal)
See parameter LF.82 for functional description.
Value table:
X3 Input State
Operating Parameter
Terminal X3 (lower terminal)
See parameter LF.83 for functional description.
Value table:
X3 Output State
Terminal strip is nonexistent at units in D- and E-housing!
Terminal strip is nonexistent at units in D- and E-housing!
Display Valency Function Output
Combivis terminal
O5 1 Signal: ready overspeed X3.13
O7 4 Relay contact: braking control X3.15/X3.16
O8 8 Signal: operating freq. warning X3.14
O9 16 Signal: delay control X3.17
O10 32 Relay contact: running open doors X3.18/X3.19
O12 128 Relay contact: main contactor ctrl. X3.20/X3.21
O14 1024 Signal: DC-monitoring X3.22
O15 4096 Signal: motor temperature warning X3.23
Display Valency Function Input
Combivis terminal
I5 1 Input signal: contactor control X3.1
I6 2 Set value correction speed: V
B
X3.2
I7 4 Set value crawl speed: V
E
X3.3
I8 8 Set value rated speed: V
N
X3.4
I9 16 Set value inspection speed: V
I
X3.5
I10 32 Set value 1st intermediate speed: V
1
X3.6
I11 64 Set value 1st intermediate speed: V
1
X3.7
