GB 62

Para. Name Address E R Res. Lower

Limit

Upper

Limit

Default Unit

LF.67 Pretorque Gain 3543 0,01 0,50 1,50 1,00 -

LF.68 Pretorque Offset 3544 0,1 -25,0 25,0 0 %

LF.69 Pretorque Direction 3545 E 1 0 1 0 -

LF.70 Brake Release Time 3546 0,001 0,300 3,000 0,300 s

LF.71 Crawl Path Optimization Vn 3547 0,1 0,0 200,0 0,0 cm

LF.72 Crawl Path Optimization V1 3548 0,1 0,0 200,0 0,0 cm

LF.73 Crawl Path Optimization V2 3549 0,1 0,0 200,0 0,0 cm

LF.74 Crawl Path Optimization Ve 354A 1 0 300 0 mm

LF.75 Ogive Function 354B 1 0 1 0 -

LF.76 Ogive Status 354C 1 0 127 0 -

LF.77 Braking Distance 354D 0,001 0,000 5,000 0,000 m

LF.78 Maximum Hight of Floor 354E 0,001 0,000 5,000 0,000 m

LF.80 Software Version 3550 R -

LF.81 Software Date 3551 R -

LF.82 X2-Input State 3552 R Table -

LF.83 X2-Output State 3553 R Table -

LF.84 X3-Input State 3554 R Table -

LF.85 X3-Output State 3555 R Table -

LF.86 Actual Set Value 3556 R 1 0 7 -

LF.87 Actual Inverter Utilization 3557 R 0,1 %

LF.88 Actual Set Speed 3558 R 0,5 rpm

LF.89 Actual Speed 3559 R 0,5 rpm

LF.90 Actual Lft Speed 355A R 0,001 m/s

LF.91 ASM-Rated Motor Torque 355B R 0,1 Nm

LF.92 Positioning Drive 355C R 0,1 cm

LF.98 Error State 3562 R Table

LF.99 Inverter State 3563 R Table

LF.A0 SSM Rated Motor Output 3564 R 0,01 kW

LF.A1 SSM Rated Motor Speed 3565 1 50 6000 4000 rpm

LF.A2 SSM Rated Motor Current 3566 0,1 0,1 1,1*Inv 3,7 A

LF.A3 SSM Rated Motor Frequency 3567 1 10 600 200 Hz

LF.A4 Static Current 3568 1 0,1 40,0 4,1 A

LF.A5 SSM Rated Motor Torque 3569 0,1 0,1 600,0 5,1 Nm

LF.A6 SSM- EMK Voltage Stabilizer 356A 1 0 2000 0 V/1000rpm

LF.A7 Winding Resistance (Ru-v) 356B 0,1 0,1 50,0 1,8 Ohm

LF.A8 Winding Inductance (Lu-v) 356C 0,1 0,1 600,0 8,1 mH

LF.b0 SSM Encoder (inc/r) 356E 1 256 10000 2048 Imp/U

LF.b1 SSM Encoder Pole Pair 356F 1 1 SSMpol 1 -

LF.b2 System Position 3570 E 1 -32768 32767 49A4h -

LF.b3 Speed Scan Rate 3571 1 0 5 3 -

LF.b4 Reso-Error-Trimming 3572 1 0 255 0 -

LF.C0 SSM KP Speed 3578 1 1 65535 230 -

LF.C1 SSM KI Speed 3579 1 1 65535 70 -

LF.C2 SSM KI Speed-Offset 357A 1 0 65535 0 -

LF.C3 SSM KP Current 357B 1 1 65535 625 -

LF.C4 SSM KI Current 357C 1 1 65535 70 -

LF.C5 SSM Torque Maximum 357D 0,1 0,0 5*Mn 1,5*Mn Nm

10. Supplement
