Keeler vantage+ - Spare Parts List

Vantage + Service Manual
2415 -P- 7011
Page 13
Issue A 07/07/2008
Spare Parts List
The following parts are common to both versions
Item Part No Description
1 E P79 - 11000 Browbar Grommet
*
2 EP39 - 53721 +2D Eye Lens
3 EP39 - 53641 Eye Piece Cap
4 EP39 - 70189 Light Shield
5 EP39 - 70197 Control Knob
*
6 EP79 - 09795 Knob Body
7 EP39 - 70178 Dimmer Control Body
11 EP39 - 70174 Metalised Label
*
12 EP79 - 09621 Cap Pl ug
13 SP72 - 00001 M2 x 8 Csk PT Screw
*
15 EP29 - 59777 Browbar
16 EP39 - 70191 Spindle Knob
*
17 EP19 - 70005 Rear Cover Moulding
18 EP39 - 70190 P.D. Slider
19 SP70 - 25117 No2 x 3/8 PT Screw
*
20 EP39 - 05121 P.D. Washer
*
21 EP39 - 53991 Eyepiece Lockring
22 EP39 - 24664 Hinge Clamp
23 EP79 - 09808 Blue Indicator Pin
24 EP39 - 70209 Centre Spindle
25 EP39 - 70245 Hinge Spacer
26 EP39 - 24656 Hinge Pin
27 1202 -P- 5808 Viewing Optics
29 EP39 - 70215 Spindle
32 EP39 - 70247 P.T.F.E. Washer
*
1202 -P- 7299 Fixings Kit
