Vantage + Service Manual
2415
-P-
7011
Page
1
Issue
A 07/07/2008
Introduction
This manual covers servicing of both the Bulb and LED illuminated versions.
The only difference lies in the Illumination Assy and the Dimmer PCB Assy
which are not interchangeable.
Damage may occur if an attempt is made to mix the Bulb and LED
Illumination Assy and Dimmer PCBs.
All drawings refer to the LED version with notes where appropriate for the bulb
version.
Service Principles
The Vantage + comprises a numbe
r of modules which have been built and
aligned in the factory. These modules can not be reliably aligned without the
special jigs and should not therefore be disassembled further than described
in this manual. There is a strong possibility of the unit de
veloping diplopia or
hyperphoria if the Viewing Optics are disassembled or adjusted.
Where a sub
-
assembly is quoted it cannot normally be reliably repaired
without special tools, adhesive and/or jigs.
