ECLIPSE – INSTALLATION/OPERATION MANUAL
Eclipse Jan-10
12
3.0 BURNER SPECIFICATIONS
CLASSIC AIR
Model Burner
Input
Nozzle
Pump
(psi)
Air
Setting
Turbulator
Output Heating CFM@ Blower Speed
USGPH L/h Btu/h Btu/h kW 0.2"wc 0.5"wc 0.2"wc 0.5"wc
KMR(F)-E1-0095-03 Riello 40 F3
0.61 2.32 85,400 0.50 60W 150 2.7 0.5 73,000 21 1084 873 4 Lo 4 Lo
0.73 2.78 102,200 0.60 60W 150 3.3 1.0 87,000 25 1084 1113 4 Lo 2 MHi
0.80 3.04 112,000 0.65 60W 150 3.8 1.2 95,000 28 1198 1200 3 MLo 1 Hi
KMR(F)-G3-0095-03
Beckett AFG
PA 402
0.59 2.24 82,600 0.50 70B 140 6.5** 70,000 21 1084 873 4 Lo 4 Lo
0.71 2.70 99,400 0.60 70B 140 6.5 84,000 25 1084 1113 4 Lo 2 MHi
0.77 2.93 107,800 0.65 70B 140 7.5 92,000 27 1198 1200 3 MLo 1 Hi
Direct Vent
KMR(F)-V1-0095-03 Riello 40 BF3
0.61 2.32 85,400 0.50 80W 150 3.6 1.0 73,000 21 1084 997 4 Lo 3 MLo
0.73 2.78 102,200 0.60 80W 150 4.0 1.5 87,000 25 1084 1200 4 Lo 1 Hi
0.80 3.04 112,000 0.65 70W 150 4.8 2.0 95,000 28 1198 1200 3 MLo 1 Hi
KMR(F)-D2-0095-03
Beckett AFG
PA 404*
0.59 2.24 82,600 0.50 70B 140 45** *** 70,000 21 1084 997 4 Lo 3 MLo
0.71 2.70 99,400 0.60 70B 140 55 *** 84,000 25 1084 1200 4 Lo 1 Hi
0.77 2.93 107,800 0.65 70B 140 67 *** 92,000 27 1198 1200 3 MLo 1 Hi
*Post Purge factory set to two minutes. **Low Firing Rate Baffle required.
***Use Air Boot Restrictor Plate.
EVO
*Post Purge factory set to two minutes. **Low Firing Rate Baffle required.
***Use Air Boot Restrictor Plate. ****Approximately 90 Btu/h CFM.
MAX
Model Burner
Input
Nozzle
Pump
(psi)
Air
Setting
Turbulator
Output Heating
USGPH L/H Btu/h Btu/h kW CFM
KMR(F)-E1-0095-E3 Riello 40 F3
0.61 2.32 85,400 0.50 60W 150 2.7 0.5 73,000 21 810*
0.73 2.78 102,200 0.60 60W 150 3.3 1.0 87,000 25 970*
0.80 3.04 112,000 0.65 60W 150 3.8 1.2 95,000 28 1055*
Direct Vent
KMR(F)-V1-0095-E3 Riello 40 BF3
0.61 2.32 85,400 0.50 80W 150 3.6 1.0 73,000 21 810*
0.73 2.78 102,200 0.60 80W 150 4.0 1.5 87,000 25 970*
0.80 3.04 112,000 0.65 70W 150 4.8 2.0 95,000 28 1055*
*Approximately 90 Btu/h CFM.
The turbulator and air settings found on this page should be used as a guide.
Model Burner
Input
Nozzle
Pump
(psi)
Air
Setting
Turbulator
Output Heating
USGPH L/h Btu/h Btu/h kW CFM****
KMR(F)-E1-0095-F3 Riello 40 F3
0.61 2.32 85,400 0.50 60W 150 2.7 0.5 73,000 21 810****
0.73 2.78 102,200 0.60 60W 150 3.3 1.0 87,000 25 970****
0.80 3.04 112,000 0.65 60W 150 3.8 1.2 95,000 28 1055****
KMR(F)-G3-0095-F3
Beckett
AFG PA
402
0.59 2.24 82,600 0.50 70B 140 6.5/0.0** *** 70,000 21 780****
0.71 2.70 99,400 0.60 70B 140 6.5/0.0 *** 84,000 25 930****
0.77 2.93 107,800 0.65 70B 140 7.5/0.0 *** 92,000 27 1020****
Direct Vent
KMR(F)-V1-0095-F3
Riello 40
BF3
0.61 2.32 85,400 0.50 80W 150 3.6 1.0 73,000 21 810****
0.73 2.78 102,200 0.60 80W 150 4.0 1.5 87,000 25 970****
0.80 3.04 112,000 0.65 70W 150 4.8 2.0 95,000 28 1055****
KMR(F)-D2-0095-F3
Beckett
AFG PA
404*
0.59 2.24 82,600 0.50 70B 140 4.5** *** 70,000 21 780****
0.71 2.70 99,400 0.60 70B 140 55 *** 84,000 25 930****
0.77 2.93 107,800 0.65 70B 140 67 *** 92,000 27 1020****
