KEER ECLIPSE MAX - TABLE - 4.pdf

Order No. Item No. Part Description
KMR-CB-0035-00 KMR-1 Cabinet Cleanout Cover
K00-CB-0101-00 KMR-2 Classic Wiring Box Cover
K00-CB-0102-00 KMR-3 Classic Wiring Box
KM0-CB-0400-00 KMR-4 Classic Front Panel Assembly
KMR-HE-0005-00 KMR-5 Heat Exchanger Assembly
KM0-CB-0040-00 KMR-6A Side Panel Assembly (Left)
KM0-CB-0041-00 KMR-6B Side Panel Assembly (Right)
KMR-CB-0100-00 KMR-7 Center Panel Assembly
KM0-CB-0034-00 KMR-8 Top Divider
K00-CB-0103-00 KMR-9 Smoke Pipe Collar
KM0-CB-0061-00 KMR-10 Front Filter Frame Assembly
KM0-CB-0062-00 KMR-11 Side Filter Frame Assembly (Left)
KM0-CB-0063-00 KMR-12 Side Filter Frame Assembly (Right)
KM0-CB-0060-00 KMR-13 Rear Filter Frame Assembly
KM0-CB-0033-00 KMR-14 Blower Door
KMR-CB-0031-00 KMR-15 Top Back Panel
KM0-CB-0030-00 KMR-16 Base Pan
3BU-10-00DD-00 KMR-17 GT10 DD Blower
KMR-KA-0018-00 KMR-18 Smoke Pipe Flange Assembly w/Gasket KMR
K00-HE-0025-00 KMF-19 Cleanout Cover Plates
KMR-20 Not Applicable
K00-HE-0155-00 KMR-21 Flange Blank K4/KD/K6/KMR/KMF (Not Shown)
3BM
-
33
-
4SDD
-
00
KMR
-
22
Motor 1/3 Direct Drive 4Speed
Direct Vent KMR Eclipse Classic Air Oil-Fired Furnace
Table - 4
3BM 33 4SDD 00
KMR 22
Motor
1/3
Direct
Drive
4Speed
4CA-00-505M-23 KMR-23 Motor Run Capacitor (5 micro farad)(Not Shown)
K00-BM-1033-50 KMR-24 Blower /Motor Assembly
3SG-0P-1030-5A KMR-25 Sight Glass (Not Shown)
K00-HE-0104-0 KMR-26 Sight Glass Ring (Not Shown)
K00-HE-0020-00 KMR-27 Complete Gasket Set (Not Shown)
K00-HE-0179-00 KMR-28
Secondar
y
Heat Exchan
g
er Baffle - each
(
Not Shown
)
3BN-0F-3SBT-00 KMR-29 F3 Riello SBT Burner
3BN-BF-3SBT-00 KMR-30 BF3 Riello SBT Burner (Direct Vent)
3BN-00-PA40-20 KMR-31 AFG-70 MB Beckett Burner PA#402
3BN-00-PA40-40 KMR-32 AFG Beckett Burner PA#404 (Direct Vent)
4FL-00-A100-3B KMR-33 Fan/High Limit Control L6064A1003B (Not Shown)
4RY-00-A100-6B KMR-34 Fan Center Relay R8285A1006B (A/C Models)
KMR-35 Not Applicable
KMR-36 Not Applicable
KMR-37 Not Applicable
KMR-38 Not Applicable
3CC-00-WALL-02 KMR-39 Target Wall (Beckett Burner Only) (Not Shown)
4SW-00-BLVT-01 KMR-40 Blocked Vent Switch
(
Not Shown
)
Please have serial number & date of manufacture ready when ordering parts
Aug-09
