KEER ECLIPSE MAX - TABLE - 3.pdf

Order No. Item No. Part Description
K00-CB-1030-00 KMF MAX-1 Smoke Pipe Collar
KMF-CB-0035-00 KMF MAX-2 Cabinet Cleanout Cover
K00-CB-0101-00 KMF MAX-3 MAX Wiring Box Cover
K00-CB-0102-00 KMF MAX-4 MAX Wiring Box
KM0-CB-0402-00 KMF MAX-5 MAX Front Panel Assembly
KMF-HE-0006-00 KMF MAX-6 Heat Exchanger Assembly
KM0-CB-0040-00 KMF MAX-7A Side Panel Assembly (Left)
KM0-CB-0041-00 KMF MAX-7B Side Panel Assemblies (Right)
KMF-CB-0100-00 KMF MAX-8 Center Panel Assembly
KM0-CB-0034-00 KMF MAX-9 Top Divider
KM0-CB-0061-00 KMF MAX-10 Front Filter Frame Assembly
KM0-CB-0062-00 KMF MAX-11 Side Filter Frame Assembly (Left)
KM0-CB-0063-00 KMF MAX-12 Side Filter Frame Assembly (Right)
KM0-CB-0060-00 KMF MAX-13 Rear Filter Frame Assembly
KM0-CB-0033-00 KMF MAX-14 Blower Door
KMF-CB-0031-00 KMF MAX-15 Top Back Panel
KM0-CB-0030-00 KMF MAX-16 Base Pan
3BU-10-00DD-00 KMF MAX-17 GT10 DD Blower
K00-HE-0100-00 KMF MAX-18 Smoke Pipe Flange Assembly K4C/K6/KD/KMF
K00-HE-0155-00 KMF MAX-19 Flange Blank K4/KD/K6/KMR/KMF
KMF MAX-20 Not Applicable
K00-HE-0025-00 KMF MAX-21 Cleanout Cover Plates (Set) (Not Shown)
3BM-50-ECM0-01 KMF MAX-22 Motor 1/2 ECM Direct Drive
Direct Vent KMF Eclipse MAX Oil-Fired Furnace
Table - 3
3BM50ECM001
KMF
MAX 22
Motor
1/2
ECM
Direct
Drive
KMF MAX-23 Not Applicable
K00-BM-1050-E3 KMF MAX-24 Blower /Motor Assembly
3SG-0P-1030-5A KMF MAX-25 Sight Glass (Not Shown)
K00-HE-0104-0 KMF MAX-26 Sight Glass Ring (Not Shown)
K00-HE-0020-00 KMF MAX-27 Complete Gasket Set (Not Shown)
K00-HE-0179-00 KMF MAX-28
Secondar
y
Heat Exchan
g
er Baffle - each
(
Not Shown
)
3BN-0F-3SBT-00 KMF MAX-29 F3 Riello SBT Burner
3BN-BF-3SBT-00 KMF MAX-30 BF3 Riello SBT Burner (Direct Vent)
KMF MAX-31 Not Applicable
4CB-00-ECML-00 KMF MAX-32 MAX (9300i) Furnace Control (Not Shown)
4CB-00-TEMP-00 KMF MAX-33 Heating Temperature Sensor (Not Shown)
KMF MAX-34 Not Applicable
4TF-00-25V0-00 KMF MAX-35 40VA Transformer (Not Shown)
4SD-00-0180-00 KMF MAX-36 Snap Disc Limit Control (180ºF) (Not Shown)
K4C-CB-0220-E3 KMF MAX-37 ECM Wire Harness (Not Shown)
K4C-CB-0200-E3 KMF MAX-38 Power Connector Harness (Not Shown)
3CC-00-WALL-02 KMF MAX-39
Not Applicable
4SW-00-BLVT-01 KMF MAX-40
Blocked Vent Switch (Not Shown)
Please have serial number & date of manufacture ready when ordering parts
May-08
