KEER ECLIPSE MAX - TABLE - 1.pdf

Order No. Item No. Part Description
K00-CB-0103-00 KMF-1 Smoke Pipe Collar
KMF-CB-0035-00 KMF-2 Cabinet Cleanout Cover
K00-CB-0101-00 KMF-3 Classic Wiring Box Cover
K00-CB-0102-00 KMF-4 Classic Wiring Box
KM0-CB-0400-00 KMF-5 Classic Front Panel Assembly
KMF-HE-0006-00 KMF-6 Heat Exchanger Assembly
KM0-CB-0040-00 KMF-7A Side Panel Assembly (Left)
KM0-CB-0041-00 KMF-7B Side Panel Assemblies (Right)
KMF-CB-0100-00 KMF-8 Center Panel Assembly
KM0-CB-0034-00 KMF-9 Top Divider
KM0-CB-0061-00 KMF-10 Front Filter Frame Assembly
KM0-CB-0062-00 KMF-11 Side Filter Frame Assembly (Left)
KM0-CB-0063-00 KMF-12 Side Filter Frame Assembly (Right)
KM0-CB-0060-00 KMF-13 Rear Filter Frame Assembly
KM0-CB-0033-00 KMF-14 Blower Door
KMF-CB-0031-00 KMF-15 Top Back Panel
KM0-CB-0030-00 KMF-16 Base Pan
3BU-10-00DD-00 KMF-17 GT10 DD Blower
K00-HE-0100-00 KMF-18 Smoke Pipe Flange Assembly K4C/K6/KD/KMF
K00-HE-0155-00 KMF-19 Flange Blank K4/KD/K6/KMR/KMF
KMF-20 Not Applicable
K00-HE-0025-00 KMF-21 Cleanout Cover Plates (Set) (Not Shown)
3BM-33-4SDD-00 KMF-22 Motor 1/3 Direct Drive 4 S
p
eed
(
Not Shown
)
Direct Vent KMF Eclipse Classic Air Oil-Fired Furnace
Table - 1
p( )
4CA-00-505M-23 KMF-23 Motor Run Capacitor (5 micro farad)(Not Shown)
K00-BM-1033-50 KMF-24 Blower /Motor Assembly
3SG-0P-1030-5A KMF-25 Sight Glass (Not Shown)
K00-HE-0104-0 KMF-26 Sight Glass Ring (Not Shown)
K00-HE-0020-00 KMF-27 Complete Gasket Set (Not Shown)
K00-HE-0179-00 KMF-28
Secondar
y
Heat Exchan
g
er Baffle - each
(
Not Shown
)
3BN-0F-3SBT-00 KMF-29 F3 Riello SBT Burner
3BN-BF-3SBT-00 KMF-30 BF3 Riello SBT Burner (Direct Vent)
3BN-00-PA40-20 KMF-31 AFG-70 MB Beckett Burner PA#402
3BN-00-PA40-40 KMF-32 AFG Beckett Burner PA#404 (Direct Vent)
4FL-00-A100-3B KMF-33 Fan/High Limit Control L6064A1003B (Not Shown)
4RY-00-A100-6B KMF-34 Fan Center Relay R8285A1006B (A/C Models)
KMF-35 Not Applicable
KMF-36 Not Applicable
KMF-37 Not Applicable
KMF-38 Not Applicable
3CC-00-WALL-02 KMF-39 Target Wall
4SW-00-BLVT-01
KMF-40
Blocked Vent Switch (Not Shown)
Please have serial number & date of manufacture ready when ordering parts
May-08
