KEER ECLIPSE MAX - TABLE - 5.pdf

Order No. Item No. Part Description
KMR-CB-0035-00 KMR EVO-1 Cabinet Cleanout Cover - No Hole
K00-CB-0101-00 KMR EVO-2 EVO Wiring Box Cover
K00-CB-0102-00 KMR EVO-3 EVO Wiring Box
KM0-CB-0401-00 KMR EVO-4 EVO Front Panel Assembly
KMR-HE-0005-00 KMR EVO-5 Heat Exchanger Assembly
KM0-CB-0040-00 KMR EVO-6A Side Panel Assembly (Left)
KM0-CB-0041-00 KMR EVO-6B Side Panel Assembly (Right)
KMR-CB-0100-00 KMR EVO-7 Center Panel Assembly
KM0-CB-0034-00 KMR EVO-8 Top Divider
K00-CB-0103-00 KMR EVO-9 Smoke Pipe Collar
KM0-CB-0061-00 KMR EVO-10 Front Filter Frame Assembly
KM0-CB-0062-00 KMR EVO-11 Side Filter Frame Assembly (Left)
KM0-CB-0063-00 KMR EVO-12 Side Filter Frame Assembly (Right)
KM0-CB-0060-00 KMR EVO-13 Rear Filter Frame Assembly
KM0-CB-0033-00 KMR EVO-14 Blower Door
KM0-CB-0031-00 KMR EVO-15 Top Back Panel
KM0-CB-0030-00 KMR EVO-16 Base Pan
3BU-10-00DD-00 KMR EVO-17 GT10 DD Blower
KMR-KA-0018-00 KMR EVO-18 Smoke Pipe Flange Assembly w/Gasket KMR
K00-HE-0025-00 KMF EVO-19 Cleanout Cover Plates (Set)
KMR EVO-20 Not Applicable
K00-HE-0155-00 KMR EVO-21 Flange Blank K4/KD/K6/KMR/KMF
3BM-33-4SDD-00 KMR EVO-22 Motor 1/3 Direct Drive 4S
p
eed
Direct Vent KMR Eclipse EVO Oil-Fired Furnace
Table - 5
3BM 33 4SDD 00
KMR
EVO 22
Motor
1/3
Direct
Drive
4Speed
4CA-00-505M-23 KMR EVO-23 Motor Run Capacitor (5 micro farad)(Not Shown)
K00-BM-1033-50 KMR EVO-24 Blower /Motor Assembly
3SG-0P-1030-5A KMR EVO-25 Sight Glass (Not Shown)
K00-HE-0104-0 KMR EVO-26 Sight Glass Ring (Not Shown)
K00-HE-0020-00 KMR EVO-27 Complete Gasket Set (Not Shown)
K00-HE-0179-00 KMR EVO-28
Secondar
y
Heat Exchan
g
er Baffle - each
(
Not Shown
)
3BN-0F-3SBT-00 KMR EVO-29 F3 Riello SBT Burner
3BN-BF-3SBT-00 KMR EVO-30 BF3 Riello SBT Burner (Direct Vent)
3BN-00-PA40-20 KMR EVO-31 AFG-70 MB Beckett Burner PA#402
3BN-00-PA40-40 KMR EVO-32 AFG Beckett Burner PA#404 (Direct Vent)
4CB-00-TEMP-01 KMR EVO-33 Heating Temperature Sensor (Not Shown)
4CB-00-0FLC-01 KMR EVO-34 EVO Furnace Control (Not Shown)
4TF-00-25V0-00 KMR EVO-35 40VA Transformer (Not Shown)
4SD-00-0180-00 KMR EVO-36 Snap Disc Limit Control (180ºF) (Not Shown)
K00-KA-0090-F3 KMR EVO-37 A/C Temperature Sensor Assembly - Optional (Not Shown)
KMR EVO-38 Not Applicable
3CC-00-WALL-02
KMR EVO-39
Target Wall (Beckett Burner Only) (Not Shown)
4SW-00-BLVT-01
KMR EVO-40
Blocked Vent Switch (Not Shown)
Please have serial number & date of manufacture ready when ordering parts
May-08
