KEER ECLIPSE MAX - TABLE - 6.pdf

Order No. Item No. Part Description
KMR-CB-0035-00 KMR MAX-1 Cabinet Cleanout Cover
K00-CB-0101-00 KMR MAX-2 MAX Wiring Box Cover
K00-CB-0102-00 KMR MAX-3 MAX Wiring Box
KM0-CB-0402-00 KMR MAX-4 MAX Front Panel Assembly
KMR-HE-0005-00 KMR MAX-5 Heat Exchanger Assembly
KM0-CB-0040-00 KMR MAX-6A Side Panel Assembly (Left)
KM0-CB-0041-00 KMR MAX-6B Side Panel Assembly (Right)
KMR-CB-0100-00 KMR MAX-7 Center Panel Assembly
KM0-CB-0034-00 KMR MAX-8 Top Divider
K00-CB-0103-00 KMR MAX-9 Smoke Pipe Collar
KM0-CB-0061-00 KMR MAX-10 Front Filter Frame Assembly
KM0-CB-0062-00 KMR MAX-11 Side Filter Frame Assembly (Left)
KM0-CB-0063-00 KMR MAX-12 Side Filter Frame Assembly (Right)
KM0-CB-0060-00 KMR MAX-13 Rear Filter Frame Assembly
KM0-CB-0033-00 KMR MAX-14 Blower Door
KMR-CB-0031-00 KMR MAX-15 Top Back Panel
KM0-CB-0030-00 KMR MAX-16 Base Pan
3BU-10-00DD-00 KMR MAX-17 GT10 DD Blower
KMR-KA-0018-00 KMR MAX-18 Smoke Pipe Flange Assembly w/Gasket KMR
K00-HE-0025-00 KMF MAX-19 Cleanout Cover Plates (Set)
KMR MAX-20 Not Applicable
K00-HE-0155-00 KMR MAX-21 Flange Blank K4/KD/K6/KMR/KMF
3BM-50-ECM0-01 KMR MAX-22 Motor 1/2 ECM Direct Drive
Direct Vent KMR Eclipse MAX Oil-Fired Furnace
Table - 6
3BM50ECM001
KMR
MAX 22
Motor
1/2
ECM
Direct
Drive
KMR MAX-23 Not Applicable
K00-BM-1033-50 KMR MAX-24 Blower /Motor Assembly
3SG-0P-1030-5A KMR MAX-25 Sight Glass (Not Shown)
K00-HE-0104-0 KMR MAX-26 Sight Glass Ring (Not Shown)
K00-HE-0020-00 KMR MAX-27 Complete Gasket Set (Not Shown)
K00-HE-0179-00 KMR MAX-28
Secondar
y
Heat Exchan
g
er Baffle - each
(
Not Shown
)
3BN-0F-3SBT-00 KMR MAX-29 F3 Riello SBT Burner
3BN-BF-3SBT-00 KMR MAX-30 BF3 Riello SBT Burner (Direct Vent)
KMR MAX-31 Not Applicable
4CB-00-ECML-00 KMR MAX-32 MAX (9300i) Furnace Control (Not Shown)
4CB-00-TEMP-00 KMR MAX-33 Heating Temperature Sensor (Not Shown)
KMR MAX-34 Not Applicable
4TF-00-25V0-00 KMR MAX-35 40 VA Transformer (Not Shown)
4SD-00-0180-00 KMR MAX-36 Snap Disc Limit Control (180ºF) (Not Shown)
K4C-CB-0220-E3 KMR MAX-37 ECM Wire Harness (Not Shown)
K4C-CB-0200-E3 KMR MAX-38 Power Connector Harness (Not Shown)
KMR MAX-39
Not Applicable
4SW-00-BLVT-01
KMR MAX-40
Blocked Vent Switch (Not Shown)
Please have serial number & date of manufacture ready when ordering parts
May-08
