KEER ECLIPSE MAX - TABLE - 2.pdf

Order No. Item No. Part Description
K00-CB-1030-00 KMF EVO-1 Smoke Pipe Collar
KMF-CB-0035-00 KMF EVO-2 Cabinet Cleanout Cover
K00-CB-0101-00 KMF EVO-3 EVO Wiring Box Cover
K00-CB-0102-00 KMF EVO-4 EVO Wiring Box
KM0-CB-0401-00 KMF EVO-5 EVO Front Panel Assembly
KMF-HE-0006-00 KMF EVO-6 Heat Exchanger Assembly
KM0-CB-0040-00 KMF EVO-7A Side Panel Assembly (Left)
KM0-CB-0041-00 KMF EVO-7B Side Panel Assemblies (Right)
KMF-CB-0100-00 KMF EVO-8 Center Panel Assembly
KM0-CB-0034-00 KMF EVO-9 Top Divider
KM0-CB-0061-00 KMF EVO-10 Front Filter Frame Assembly
KM0-CB-0062-00 KMF EVO-11 Side Filter Frame Assembly (Left)
KM0-CB-0063-00 KMF EVO-12 Side Filter Frame Assembly (Right)
KM0-CB-0060-00 KMF EVO-13 Rear Filter Frame Assembly
KM0-CB-0033-00 KMF EVO-14 Blower Door
KMF-CB-0031-00 KMF EVO-15 Top Back Panel
KM0-CB-0030-00 KMF EVO-16 Base Pan
3BU-10-00DD-00 KMF EVO-17 GT10 DD Blower
K00-HE-0100-00 KMF EVO-18 Smoke Pipe Flange Assembly K4C/K6/KD/KMF
K00-HE-0155-00 KMF EVO-19 Flange Blank K4/KD/K6/KMR/KMF
KMF EVO-20 Not Applicable
K00-HE-0025-00 KMF EVO-21 Cleanout Cover Plates (Set) (Not Shown)
3BM-33-4SDD-00 KMF EVO-22 Motor 1/3 Direct Drive 4 S
p
eed
(
Not Shown
)
Direct Vent KMF Eclipse EVO Oil-Fired Furnace
Table - 2
3BM 33 4SDD 00
KMF
EVO 22
Motor
1/3
Direct
Drive
4
Speed
(Not
Shown)
4CA-00-505M-23 KMF EVO-23 Motor Run Capacitor (5 micro farad)(Not Shown)
K00-BM-1033-50 KMF EVO-24 Blower /Motor Assembly
3SG-0P-1030-5A KMF EVO-25 Sight Glass (Not Shown)
K00-HE-0104-0 KMF EVO-26 Sight Glass Ring (Not Shown)
K00-HE-0020-00 KMF EVO-27 Complete Gasket Set (Not Shown)
K00-HE-0179-00 KMF EVO-28
Secondar
y
Heat Exchan
g
er Baffle - each
(
Not Shown
)
3BN-0F-3SBT-00 KMF EVO-29 F3 Riello SBT Burner
3BN-BF-3SBT-00 KMF EVO-30 BF3 Riello SBT Burner (Direct Vent)
3BN-00-PA40-20 KMF EVO-31 AFG-70 MB Beckett Burner PA#402
3BN-00-PA40-40 KMF EVO-32 AFG Beckett Burner PA#404 (Direct Vent)
4CB-00-TEMP-01 KMF EVO-33 Heating Temperature Sensor (Not Shown)
4CB-00-0FLC-01 KMF EVO-34 EVO Furnace Control (Not Shown)
4TF-00-25V0-00 KMF EVO-35 40VA Transformer (Not Shown)
KMF EVO-36 Not Applicable
K00-KA-0090-F3 KMF EVO-37 A/C Temperature Sensor Assembly - Optional (Not Shown)
KMF EVO-38 Not Applicable
3CC-00-WALL-02 KMF EVO-39
Target Wall
4SW-00-BLVT-01 KMF EVO-40
Blocked Vent Switch (Not Shown)
Please have serial number & date of manufacture ready when ordering parts
May-08
