ECLIPSE – INSTALLATION/OPERATION MANUAL
Eclipse Jan-10
17
Warm air registers blowing too hot
Blower running slow Speed blower up (Classic Air).
Return air restricted Open up return air ductwork to ensure adequate airflow.
Nozzle too large Lower nozzle size to suit ductwork.
Noisy operation
Loose blower wheel Tighten wheel set screw or replace.
Blower wheel hitting housing Center wheel in housing.
Damaged motor bearings Replace blower motor.
Faulty oil pump Repair or replace oil pump. Reset to correct pressure.
Air leak in oil line Tighten all connections.
Vacuum too high on pump Check pump vacuum. Check filters and pump screen.
8.1 MAX/EVO LED INDICATORS
Refer to decal on inside of wiring box cover.
GREEN LED (Status)
Slow Green Standby.
Fast Green B1-B2 Energized.
Solid Green System Fault.
In this case the Red LED will flash a number of times to indicate probable cause.
1. Disconnect power
2. Correct error
3. Re-connect power
RED (Diagnostic)
On Power Up of system, the RED LED will flash. If there is a problem detected the system
will try two times to diagnose and correct the problem (approx. 80 seconds). If problem
persists RED LED error code will flash.
RED 3 Flashes Heat/Aux Sensor Trouble
a) Ensure sensor or Jumper Plug (9300i only) is fully plugged into connector.
b) Otherwise, Replace Sensor or Jumper Plug (9300i only).
RED 4 Flashes B1 Output Trouble
a) Check for wiring error.
b) Otherwise replace control.
RED 5 Flashes System Trouble
a) Replace control.
