Keiser 001133BP - Technical Specifications; 07_Equipment Specifications; 07_Technical Data

07
AIR300 LEG EXTENSION PRO | OPERATION MANUAL
TECHNICAL SPECIFICATIONS
Figure 2. Air300 Leg Extension Pro Equipment Specications
45 inches
(1,143 mm)
39 inches
(991 mm)
40 inches
(1,016 mm)
150 lbs
(68 kg)
EQUIPMENT SPECIFICATIONS
TECHNICAL DATA
AIR STORAGE TANKS
The equipment contains two air storage tanks (air accumulator) with the following operating parameters:
POWER
• 1.5V D Alkaline Batteries (quantity 2, Keiser PN 966500)
• 3V CR2032 Lithium Coin Cell Battery (quantity 1)
Permanently attached, not serviceable. Contact Keiser Customer Support for service.
Maximum working pressure: 125 psi (8.6 bar)
Maximum working temperature: 104ºF (40ºC)
Minimum working temperature: 32ºF (0ºC)
Maximum vessel capacity: 68 in
3
(1.11 L) per tank
Model No. Device Label (Short Description) Device Full Description
001133BP A300 LEG EXT PRO-BLK-PWR Air 300 Leg Extension Pro, Black (color), Power (additional display feature)
001133XP A300 LEG EXT PRO-SPC-PWR Air 300 Leg Extension Pro, Special (color), Power (additional display feature)
See Figure 2 for Air300 Leg Extension Pro dimensions and
weight.
• Resistance Range 0 – 236 lbs (0 – 107 kg), change
resistance in 1 lb/kg increments
• Independent Exercise Arms
• 135° Range of Motion
• Adjustable Seat Back
• Maximum user weight limit:
441 lbs (200 kg)
