Keiser 3020XP - Operation: Functional Trainer Overview; Component Identification

07
OPERATION MANUAL
FUNCTIONAL TRAINER
FUNCTIONAL TRAINER OVERVIEW
Pulley
1
Cable Link
5
eChip
15
Pulley Housing
2
Power Display
11
Handle
6
Floor Mount Plate
16
Cable
3
Arm
12
Arm Adjustment Knob
13
Accessory Hook
7
Clevis
4
Arm Position Plate
14
9
Instructional Placard
Increase/Decrease (+/-) Thumb Buttons
8
Quick Disconnect with Tube
10
OPERATION
Free-standing
Functional Trainer
12 inch (305 mm)
Base Extension
Functional Trainer
Floor Mounted Triple Trainer
Free-standing Triple Trainer
Figure 4. Floor Mounted Functional Trainer
3
2
5
4
6
7
11
9
15
16
14
12
8
1
13
10
