Keiser INFINITY 003020BP - Technical Specifications; 07_Equipment Specifications; 07_Technical Data

07
FUNCTIONAL TRAINER | OPERATION MANUAL
See Figure 2 for Functional Trainer dimensions
and weight.
Resistance Range:
50 lbs (23 kg)
each Handle
Cable Length:
140 inches (3,556 mm)
single handle
70 inches (1,778 mm)
both handles together
EQUIPMENT SPECIFICATIONS
Figure 2. Equipment Specications
89 inches
(2,261 mm)
59 inches
(1,499 mm)
96 inches
(2,439 mm)
29 inches
(737 mm)
118 lbs
(54 kg)
32 inches
(813 mm)
15.5 inches
(394 mm)
11.5 inches
(292 mm)
Floor Mounted
Functional Trainer
92 inches
(2,337 mm)
84 inches
(2,134 mm)
96 inches
(2,439 mm)
47 inches
(1,194 mm)
369 lbs
(168 kg)
62 inches
(1,575 mm)
Free-standing
Functional Trainer
TECHNICAL DATA
AIR STORAGE TANK
The equipment contains an air storage tank
(air accumulator) with the following operating
parameters:
POWER
• 1.5V D Alkaline Batteries (quantity 2,
Keiser PN 966500)
• 3V CR2032 Lithium Coin Cell Battery
(quantity 1)
Permanently attached, not serviceable.
Contact Keiser Customer Support for service.
Maximum working pressure: 125 psi (8.6 bar)
Maximum working temperature: 104ºF (40ºC)
Minimum working temperature: 32ºF (0ºC)
Maximum vessel capacity: 144 in
3
(2.36 L)
TECHNICAL SPECIFICATIONS
Model No. Device Label (Short Description) Device Full Description
003020BP FUNCT TRAINER-BLK-PWR Functional Trainer, Black (color), Power (additional display feature)
003020XP FUNCT TRAINER-SPC-PWR Functional Trainer, Special (color), Power (additional display feature)
