Keithley 2182 Service Manual

6-4 Replacement Parts
Table 6-1
Motherboard parts list (continued)
Circuit designation Description Keithley part no.
CN701 MODIFIED POTTING BOX 2182-321A
CN702 SHIELD CN-68
CN703 SHIELD CN-70
CR101,102,316,317,654 DIODE, DUAL SWITCHING, BAV99L RF-82
CR301-309,311-314 DIODE, SWITCHING, MMSD914T19 RF-112
CR310 DIODE,BRIDGE,VM18 RF-52
CR315 DIODE,SILICON,W04M (CASE WM) RF-46
CR501,CR653,CR606,CR607,CR651,CR65
2
DIODE, DUAL HSM-2822T31 RF-95
CR502,CR602,CR603 DIODE, SWITCHING, MMBD914 RF-83
CR601,CR604 DIODE, DUAL COMMON ANODE
BAW56LT2
RF-98
J1005 CONN, HEADER STRAIGHT SOLDER
PIN
CS-368-16
J1006 CONN, MICRODIN W/GND FINGERS CS-792
J1007 CONN, RT ANGLE, MALE, 9 PIN CS-761-9
J1008 CONN,RIGHT ANGLE,24 PIN CS-501
J1014 LATCHING HEADER,FRICTON, SGL
ROW
CS-724-3
J1015 CONNECTOR, HEADER CS-784-4
J1016 CONN, MALE, 5-PIN (MOLEX 42491) CS-784-5
J1017 CONN, BNC CS-547
L101,L502,L503,L504 FERRITE CHIP 600 OHM BLM32A07 CH-62
L102,L103,L501,L505 FERRITE CHIP 600 OHM BLM32A07 CH-62
L301,L302 CHOKE CH-61
L650,L653,L654 CHOKE, EMI CH-57
L651,L652 CHOKE, 100UH CH-14
L655,L601,L602 CHOKE, 22UH CH-66-22
LS101 BEEPER, 5V, 30MA, BRT1209P-06-C EM-5
Q101,301,303,605,752,631,632 TRANS, NPN, MMBT3904 TG-238
Q302,304,606,751,626,636 TRANS, PNP, MMBT3906L TG-244
Q501-504,675,676,640 TRANS, N-MOSFET, VN0605T TG-243
Q505,625,628,629,650,659,660,665,672-
674
TRANS, N CHANNEL JFET, SNJ132199 TG-294
Q506,Q635 TRANS, N-CHAN JFET, SST4393 TG-263
Q601,Q602 TRANS PNP, BC 856BL TG-287
Q603,Q607 TRANS,NPN COMP SILICON
AMP,MPS8099
TG-157
Q604,Q610 TRANS,PNP COMP SILICON
AMP,MPS8599
TG-158
Q608,Q609 TRANS, NPN SILICON, BC846BL, TG-278
Q611,Q612,Q613,Q614 TRANS,N CHAN MOSPOW FET,2N7000 TG-195
Q615-618,637,655-657 TRANS, PNP, BC860C TG-323
