Keithley 2182 Service Manual

Replacement Parts 6-5
Circuit designation Description Keithley part no.
Q619,Q652 TRANS, NPN PAIR, LM394 TG-142
Q620,Q621 TRANS, N CHANNEL JFET, SST4118 TG-347
Q624,U651 SELECTED TRANSISTOR 2010-600A
Q627,Q630 TRANS,N CHANNEL JFET TG-225
Q633,Q634,Q638,Q670,Q639,Q507 TRANS, N CHANNEL JFET, SNJ132199 TG-294
Q658,Q663,Q664,Q622,Q623,Q671 TRANS,N CHANNEL FET,2N4392 TG-128-1
Q661,Q662 TRANS, N-CHAN MOSFET, TN254ON8 TG-274
Q666,Q667 TRANS,P-FET, MTP2N90 TG-232
R101,R507,R525,R526,124,149,153,162,
168
RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R102-107,110-112,117-120,123,515,
165,171
RES, 4.75K, 1%, 100MW, THICK FILM R-418-4.75K
R113,R136,R318,R169 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R114,137,518,520,522,759-761,163,521 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R115,R116,R502,R503 RES, 2.21K, 1%, 100MW, THICK FILM R-418-2.21K
R121,127-129,504,516,611,612,628,629 RES, 100, 1%, 100MW, THICK FILM R-418-100
R122 RES, 10, 10%, 100MW, THICK FILM R-418-10
R125,138,148,306,307,509 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R131,R130 RES, 100, 1%, 100MW, THICK FILM R-418-100
R132,R308 RES, 357, 1%, 100MW, THICK FILM R-418-357
R133-135,151,152,154,512 RES, 475, 1%, 100MW, THICK FILM R-418-475
R139 RES, 49.9, 1%, 100MW THICK FILM R-418-49.9
R140,R633 RES, 2.21K, 1%, 100MW, THICK FILM R-418-2.21K
R141 RES, 200, 1%, 100MW, THICK FILM R-418-200
R142,R145 RES, .0499, 1%, 100MW, THICK FILM R-418-.0499
R150 RES, 475, 1%, 100MW, THICK FILM R-418-475
R155 RES, 332, 10%, 125MW METAL FILM R-391-332
R157 RES,243K, 1%, 125MW, METAL FILM R-391-243K
R158 RES, 90.9K, 1%, 125mW, METAL FILM R-391-90.9K
R159 RES,1K, 5% 250MW, METAL FILM R-376-1K
R160 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R161,R674,R686 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R164,R170 RES, 100K, 1%, 100MW THICK FILM R-418-100K
R301,R302,R303 RES,10,5%,125MW,METAL FILM R-375-10
R304,R311 RES, 15k, 1%, 100MW, THICK FILM R-418-15K
R305 RES, 33.2K, 1%, 100MW, THICK FILM R-418-33.2K
R309,R314 RES, 10K, 1%, 125mW, METAL FILM R-391-10K
R310,R316 RES, 100, 1%, 125mW, METAL FILM R-391-100
R312,R315 RES, 20K, 1%, 100MW THICK FILM R-418-20K
R317,R631 RES, 15K, 1%, 125mW, METAL FILM R-391-15K
R319,R320,R321 RES, 3.01K, 1%, 100MW THICK FILM R-418-3.01K
R322 RES, 100K, 1%, 125mW, METAL FILM R-391-100K
R323 RES, 150, 5%, 250MW, METAL FILM R-376-150
Table 6-1
Motherboard parts list (continued)
