Keithley 2182 Service Manual

6-6 Replacement Parts
Table 6-1
Motherboard parts list (continued)
Circuit designation Description Keithley part no.
R501 RES, 1.28M, .1%, 1/8W METAL FILM R-176-1.28M
R505 RES, 5.11K, 1%, 100MW, THICK FILM R-418-5.11K
R506,R691 RES, 470,5%, 125MW, METAL FILM R-375-470
R508,R625 RES, 24.9K, 1%, 100MW, THICK FILM R-418-24.9K
R510 RES, 49.9K, 1%, 100MW THICK FILM R-418-49.9K
R511 RES,4.02K,1%,100MW, THICK FILM R-418-4.02K
R513 RES, 34K, 1%, 100MW, THICK FILM R-418-34K
R514 RES, 82.5, 1%, 100MW, THICK FILM R-418-82.5
R517,R523 RES, 1M, 1%, 100MW, THICK FILM R-418-1M
R519 RES, 10, 10%, 100MW, THICK FILM R-418-10
R524,667,668,602,635,639,676,680,683,698 RES, 49.9K, 1%, 100MW THICK FILM R-418-49.9K
R600 RES, 450, .1%, 1/8W METAL FILM R-377-450
R601 RES, 511, 1%, 100MW, THICK FILM R-418-511
R603,R604 RES, 3.01K, 1%, 125MW, METAL FILM R-391-3.01K
R605 RES, 511, 1%, 100MW, THICK FILM R-418-511
R608,R609,R685 RES, 1K, 1%, 125mW, METAL FILM R-391-1K
R610,R684,R626,R699,R703 RES, 1K, 1%, 125mW, METAL FILM R-391-1K
R613 RES, 6.98K, 1%, 125MW, METAL FILM R-391-6.98K
R614 RES, 4.99K, 1%, 100MW THICK FILM R-418-4.99K
R615,R618 RES, 604, 1%, 100MW THICK FILM R-418-604
R616,R617 RES, 392, 1%, 100MW, THICK FILM R-418-392
R622 RES, 1.07K, .1%, .125W THIN FILM R-456-1.07K
R623,R657 RES, 20, 1%, 100MW, THICK FILM R-418-20
R624,R627 RES, 200, 1%, 100MW, THICK FILM R-418-200
R630,R655,R658,R660 RES, 1K, 1%,125MW THIN FILM R-423-1K
R632,R619 RES, 1K, 1%,125MW THIN FILM R-423-1K
R637 PRECISION DIVIDER TF-256
R641,R717 RESISTOR, PRECISION R-410-100
R642,R659 RES,49.9K,1%,125MW, METAL FILM R-391-49.9K
R644 RES, 26.7K, 1%, 125mW,METAL FILM R-391-26.7K
R645,646,678,634,638,643,649,675,682,697 RES,49.9K,1%,125MW, METAL FILM R-391-49.9K
R648 RES, 4.5K, .1%, 1/8W METAL FILM R-377-4.5K
R650,652,661,662,640,647,669,708,711 RES, 1K, 1%, 125mW, METAL FILM R-391-1K
R651 RES, 6.65K, 1%, 125MW, METAL FILM R-391-6.65K
R653 RES, 137, 1%, 125MW, METAL FILM R-391-121
R654 RES, 15K, 1%, 125mW, METAL FILM R-391-15K
R656 RES, 499, 1%, 125MW, METAL FILM R-391-499
R663 RES, 26.7K, 1%, 125mW,METAL FILM R-391-26.7K
R664 RES, 9.09K, .1%, 1/10W, METAL FILM R-263-9.09K
R665 RES, .1%, 1/8W METAL FILM R-377-1K
R666 RES, 100, .1%, 1/10W, METAL FILM
