Keithley 2280 Series User Manual

Two-wire (local sensing) DUT connection to rear panel
When making two-wire connections with the Series 2280, you must
short both Output Hi and Sense Hi and Output Lo and Sense Lo with
the shorting jumpers. If you do not do this, the display will show
incorrect voltage output readings.
After making the connections, slide the cable housing over the
output mating connector and wires.
Failure to install the cable housing may result in personal injury or
death due to electric shock.

Keithley 2280 Series Specifications

General

Brand	Keithley
Model	2280 Series
Category	Power Supply
Language	English
