Keithley 2280 Series User Manual

Overview of the front-panel options
The front panel of the Series 2280 allows you to set up most
instrument functions and features and perform sourcing and
measuring operations. The front panel includes:
 A high-resolution color display that allows you to access
instrument settings and measurement readings
 Keys that select menu options and start measurement operations
 A navigation control that can be used to select screen options
 An output ON/OFF switch that turns the source output on or
off
 Front-panel binding posts for output connections
ENTER and EXIT keys
The ENTER key selects a highlighted option. In most cases, it
opens the menu or dialog box that allows you to change settings for
that option.
The EXIT key returns to the previous menu or closes a dialog box.
For example, if you are in the Menu screen, pressing EXIT returns
you to the Home screen.
TRIGGER key
The action of the TRIGGER key depends on the trigger method
that is selected:
 If manual triggering is selected, TRIGGER causes the instrument
to make a measurement.
 If the trigger model is in idle, TRIGGER initiates the trigger
model.
Front-panel user interface overview
The front-panel user interface gives you quick access to source
settings, measure settings, system configuration, instrument status,
reading buffer information, and other instrument functionality.

Keithley 2280 Series Specifications

General

Brand	Keithley
Model	2280 Series
Category	Power Supply
Language	English
