Keithley 2280 Series User Manual

Specify a measurement range
Y ou can set ranges for the measurement values. Y ou can set specific
ranges or allow the instrument to choose the ranges automatically.
The measurement range determines the full-scale input for the
measurement. The measurement range also affects the accuracy of
the measurements and the maximum signal that can be measured.
The Series 2280 has multiple current measurement ranges and one
voltage range. The ranges are listed in the following table.
To set the ranges from the Home screen:
1. Press the HOME key and select R ang e button. The Range
dialog box is displayed.
2. Use the up and down arrow soft keys to select the range. The
Home page is updated with the new range setting. Press
ENTER or EXIT to close the Range dialog box.
To set the ranges from the Menu screen:
1. Press the MENU key.
2. Highlight the Settings icon under Measure using either the
navigation control or the softkeys. Press ENTER.
3. On the MEASURE SETTINGS page, select the button next to
R ang e. The Range dialog box is displayed.
4. Select the range. Y ou are returned to the MEASURE
SETTINGS screen.
See the " General operation" section of the Reference Manual for
additional details and remote interface examples.
Model number
Current measurement
range
Voltage
measurement
range
2280S-32-6
10 A
32 V
1 A
100 mA
10 mA
2280S-60-3
10 A
60 V
1 A
100 mA
10 mA
