Test
To simulate a battery with 2281S-20-6 using the
front panel:
1. Select the battery simulator function on the startup
screen.
2. Select Model in soft key area 1.
3. Choose 10.mdl, since it is the model of a cellphone
Li-Ion battery normally seen in the market with a voltage
range of 3.7 V to 4.2 V.
4. Press the MENU key.
5. Under Battery, select Settings.
6. Set Method to Dynamic. The Voc, SOC, and ESR
of the simulated battery will change according to the
discharging states, just like a real battery.
7. Return to the battery simulator home screen by pressing
HOME on the front panel.
8. Select I-Limit in soft key area 2 and set the current limit.
The maximum current from the 2281S to the DUT cannot
be set higher than 6.1 A.
To test a product at a specic battery state, you can
either select an SOC value or an open-circuit voltage
value. The values of the other parameters and internal
resistance adjust based on the battery model. Alternatively,
you can discharge the battery starting at 100% SOC.
You can adjust the capacity of the model by going to soft key
area 2, selecting the Capacity soft key, and setting the value.
If you do not set this value, the battery model denes the
capacity of the battery.
9. On the front panel, press the OUTPUT key to start the
battery simulation.
