Keithley 2400 Service Manual

Table B-3
:CALibration:PROTected:SOURce parameter ranges
Source range
First parameter
(negative full scale)
Second parameter
(negative zero)
Third parameter
(positive full scale)
Fourth parameter
(positive zero)
0.2V
2V
20V
200V
1µA
10µA
100µA
1mA
10mA
100mA
1A
-0.18 to -0.22
-1.8 to -2.2
-18 to -22
-180 to -220
-0.9E-6 to -1.1E-6
-9E-6 to -11E-6
-90E-6 to -110E-6
-0.9E-3 to -1.1E-3
-9E-3 to -11E-3
-90E-3 to -110E-3
-0.9 to -1.1
-0.002 to +0.002
-0.02 to +0.02
-0.2 to +0.2
-2 to +2
-1E-8 to +1E-8
-1E-7 to +1E-7
-1E-6 to +1E-6
-1E-5 to +1E-5
-1E-4 to +1E-4
-1E-3 to +1E-3
-1E-2 to +1E-2
+0.18 to +0.22
+1.8 to +2.2
+18 to +22
+180 to +220
+0.9E-6 to +1.1E-6
+9E-6 to +11E-6
+90E-6 to +110E-6
+0.9E-3 to +1.1E-3
+9E-3 to +11E-3
+90E-3 to +110E-3
+0.9 to +1.1
-0.002 to +0.002
-0.02 to +0.02
-0.2 to +0.2
-2 to +2
-1E-8 to +1E-8
-1E-7 to +1E-7
-1E-6 to +1E-6
-1E-5 to +1E-5
-1E-4 to +1E-4
-1E-3 to +1E-3
-1E-2 to +1E-2
B-8 Command Reference
:DATA?
(:CALibration:PROTected:SENSe:DATA?)
(:CALibration:PROTected:SOURce:DATA?)
Purpose To request the calibration constants for the active range.
Format :cal:prot:sens:data?
:cal:prot:sour:data?
Response Four comma-separated ASCII floating-point constants.
Description The :CAL:PROT:SENS:DATA? and :CAL:PROT:SOUR:DATA? queries
request the calibration constants for the active range of the sense and source
functions respectively. The four returned constants are in ASCII floating-
point format delimited by commas.
Note To request the appropriate constants (1) select the source or sense function,
(2) choose the desired range, and (3) send the desired :DATA? query.
Example :SENS:FUNC ‘VOLT:DC’ Select DC sense function.
:SENS:VOLT:DC:RANGE 0.2 Choose 200mV range.
:CAL:PROT:SENS:DATA? Request cal constants.
