6-5 Model 2400 Service Manual
Replaceable Parts
2400-902-01 (G - Feb 2006)
CR500-503 ULTRAFAST POWER RECTIFIER RF-107
CR508-511,520,521 DIODE, CONTROLLED AVALANCHE,
BYD17GSO
RF-91
CR512,513 DIODE ZENER, 12V, MMSZ11T1 DZ-112
CR517,519 ULTRAFAST POWER RECTIFIER RF-106
CR600,238 DIODE, DUAL HSM-2822T31 RF-95
CR601 DIODE, SCHOTTKY, BAT42 RF-78
J1001 CONN, HEADER STRAIGHT SOLDER PIN CS-368-10
J1002 CONN, HEADER STRAIGHT SOLDER PIN CS-368-16
J1003 CONN, HEADER STRAIGHT SOLDER PIN CS-368-14
J1034 LATCHING HEADER, FRICTON, SGL ROW CS-724-3
K200-205 N.C RELAY, 1 FORMB, AQV214S RL-176
K206 RELAY, REED, HI-VOLT/ISOLATION RL-152
K207,208 RELAY, MINI SIGNAL REL RL-163
K211 RELAY, SURFACE MOUNT RL-188
L201 COIL CH-72-1
L600,601,602 FERRITE CHIP 600 OHM BLM32A07 CH-62
L603 FERRITE CHIP 600 OHM BLM32A07 CH-62
Q200-207,240,241 TRANS, N CHANNEL JFET, SNJ132199 TG-294
Q208,210,212,214,216,218 TRANS, NPN CATV SILICON, MPSH17 TG-221
Q209,211,213,215,217,219 TRANS, CURRENT REGULATOR, CR430 TG-219
Q220,225 TRANS, NPN SILICON, MJE340 TG-209
Q221,226 TRANS, PNP POWER, MJE350 TG-210
Q222,224 TRANS, N-CHAN JFET, SST4393 TG-263
Q234-239,244-246,255,256,400,401,404 TRANS, N-MOSFET, VN0605T TG-243
Q242,243 TRANS, N-CHAN MOSFET, TN254ON8 TG-274
Q402,409 TRANS, N-CHAN DMOS FET, TN2504N8 TG-261
Q403,406,407,408 TRANS, N-CHAN JFET, SST109 TG-266
Q223,405,410,411,602-607 TRANS, N-MOSFET, VN0605T TG-243
Q412,414 TRANS, N-MEGAFET, RFD 14N05LSM TG-267
Q413 TRANS, P-CHAN, MOSFET, TP0610T TG-259
Q415 TRANS, P-FET, MTP20P06 TG-229
Q500,502,514,516 TRANS, N-CHANNEL FET, IRF630 TG-214
Q501,503,505,508,510,512,513,528 TRANS, NPN, MMBT3904 TG-238
Q504 TRANS, NPN, TIP48 TG-314
Q506,520,601,529 TRANS, PNP, MMBT3906L TG-244
Q507 TRANS, PMP, MJE5731A TG-315
Q509,511,523,525 TRANS, P-CHANNEL 200V FET, IRF9630 TG-215
Table 6-1 (cont.)
Analog board parts list
Circuit designation Description
Keithley
part no.
To Next Page
