SPECIFICATIONS
SPEC-2400
A 18217 Released SZ 1/11/96
B 18249 Revised SZ 3/6/96
C 18608 Revised SZ 4/22/96
D 18863 Revised SZ 7/29/96
E 19739 Revised SZ 10/4/98
F 27103 Revised SZ 5/10/02
G 27953 Revised SZ 3/04/03
H 29424 Revised SZ 2/25/04
HW 2/25/04
Rev. H
Page 2 of 3
2400, 2400-LV and 2400-C SourceMeter
®
Specifications
MEASURE SPECIFICATIONS
1,2
VOLTAGE MEASUREMENT ACCURACY (LOCAL OR REMOTE
SENSE)
MODEL RANGE
DEFAULT
RESOLUTION
INPUT
RESISTANCE
ACCURACY (1 Year)
23°C ±5°C
±(% rdg. + volts)
200.00 mV 1 µV
>10 GΩ
0.012% + 300 µV
2.00000 V 10 µV
>10 GΩ
0.012% + 300 µV
20.0000 V 100 µV
>10 GΩ
0.015% + 1.5 mV
2400-C and
2400 Only:
200.000 V 1 mV
>10 GΩ
0.015% + 10 mV
TEMPERATURE COEFFICIENT (0°-18°C & 28°-50°C): ±(0.15 × accuracy
specification)/ °C.
CURRENT MEASUREMENT ACCURACY (LOCAL OR REMOTE
SENSE)
RANGE
DEFAULT
RESOLUTION
VOLTAGE
BURDEN
3
ACCURACY (1 Year)
23°C ±5°C
±(% rdg. + amps)
1.00000 µA 10 pA <1 mV 0.029% + 300 pA
10.0000 µA 100 pA <1 mV 0.027% + 700 pA
100.000 µA 1 nA <1 mV 0.025% + 6 nA
1.00000 mA 10 nA <1 mV 0.027% + 60 nA
10.0000 mA 100 nA <1 mV 0.035% + 600 nA
100.000 mA 1 µA <1 mV 0.055% + 6 µA
1.00000 A 10 µA <1 mV 0.22% + 570 µA
TEMPERATURE COEFFICIENT (0°-18°C & 28°-50°C): ±(0.10 × accuracy
specification)/ °C.
CONTACT CHECK SPECIFICATIONS
SPEED: 350µs for verification and notification.
CONTACT CHECK:
2Ω 15Ω 50Ω
No contact check failure <1.00Ω <13.5Ω <47.5Ω
Always contact check failure
>3.00Ω >16.5Ω >52.5Ω
RESISTANCE MEASUREMENT ACCURACY (LOCAL OR REMOTE SENSE)
RANGE
DEFAULT
RESOLUTION
DEFAULT TEST
CURRENT
NORMAL
ACCURACY (23°C ±5°C)
1 YEAR,
±(% rdg. + ohms)
ENHANCED
ACCURACY (23°C ±5°C)
5
1 YEAR,
±(% rdg. + ohms)
<2.00000 Ω
4
10 µΩ
- Source I
ACC
+ Meas. V
ACC
Meas I
ACC
+ Meas. V
ACC
20.0000 Ω 100 µΩ
100 mA
0.10% + 0.003 Ω 0.07% + 0.001 Ω
200.000 Ω 1 mΩ
10 mA
0.08% + 0.03 Ω 0.05% + 0.01 Ω
2.00000 kΩ 10 mΩ
1 mA
0.07% + 0.3 Ω 0.05% + 0.1 Ω
20.0000 kΩ 100 mΩ
100 µA
0.06% + 3 Ω 0.04% + 1 Ω
200.000 kΩ 1 Ω
10 µA
0.07% + 30 Ω 0.05% + 10 Ω
2.00000 MΩ 10 Ω
1 µA
0.11% + 300 Ω 0.05% + 100 Ω
20.0000 MΩ 100 Ω
1 µA
0.11% + 1 kΩ 0.05% + 500 Ω
200.000 MΩ 1 kΩ
100 nA
0.66% + 10 kΩ 0.35% + 5 kΩ
>200.000 MΩ
4
- - Source I
ACC
+ Meas. V
ACC
Meas I
ACC
+ Meas. V
ACC
TEMPERATURE COEFFICIENT (0°-18°C & 28°-50°C): ±(0.15 × accuracy
specification)/ °C.
SOURCE I MODE, MANUAL OHMS: Total uncertainty = I source accuracy
+ V measure accuracy (4-wire remote sense).
SOURCE V MODE, MANUAL OHMS: Total uncertainty = V source
accuracy + I measure accuracy (4-wire remote sense).
6-WIRE OHMS MODE: Available using active ohms guard and guard sense.
Max. Guard Output Current: 50mA (except 1A range). Accuracy is load
dependent. Refer to White Paper no. 2033 for calculation formula.
GUARD OUTPUT IMPEDANCE: <0.1Ω in ohms mode.
1. Speed = Normal (1 PLC). For 0.1 PLC, add 0.005% of range to offset specifications,
except 200mV, 1A ranges, add 0.05%. For 0.01 PLC, add 0.05% of range to offset
specifications, except 200mV and 1A ranges, add 0.5%.
2. Accuracies apply to 2- or 4-wire mode when properly zeroed.
3. 4-wire mode.
4. Manual ohms only.
5. Source readback ON, offset compensation ON, add system noise but don’t include offsets.
