A-6 Specifications
2430-C Specifications
Source Specifications
1
Voltage Programming Accuracy (remote sense)
Accuracy (1 Year) Noise
Programming 23 C –5 C (peak-peak)
Range Resolution –% rdg. + volt s 0.1Hz 10Hz
200.000 m V 5 V 0.02% + 600 V 10 V
2.00000 V 50 V 0.02% + 600 V 50 V
20.0000 V 500 V 0.02% + 2.4 m V 500 V
100.000 V 2.5 m V 0.02% + 12 m V 2.5 m V
TEMPERATURE COEFFICIENT (0 18 C & 28 50 C): –(0.15 ∞ accuracy specification)/ C.
MAX. OUTPUT POWER: 110W (four quadrant source or sink operation, DC mode).
SOURCE/SINK LIMITS: 5% over nominal for current and volt age.
VOLTAGE REGULATION: Line: 0.01% of range. Load: 0.01% of range + 100 V.
NOISE 10Hz 1MHz (p-p): 50mV maximum, resistive load.
OVER VOLTAGE PROTECTION: User selectable values, 5% tolerance. Factory default = None.
CURRENT LIMIT: Bipolar current limit (compliance) set with single value. Min. 0.1% of range.
OVERSHOOT:<0.1% typical (full scale step, resistive load, 10mA range).
Current Programming Accuracy (local or remote sense)
Accuracy (1 Year) Noise
Programming 23 C –5 C (peak-peak)
Range Resolution –% rdg. +amps 0.1Hz 10Hz
10.0000 A 500 pA 0.033% + 2 nA 50 pA
100.000 A 5 nA 0.031% + 20 nA 500 pA
1.00000 m A 50 nA 0.034% + 200 nA 5 nA
10.0000 m A 500 nA 0.045% + 2 A 50 nA
100.000 m A 5 A 0.066% + 20 A 500 nA
1.00000 A
2
50 A 0.067% + 400 A 100 A
3.00000 A
2
/ 500 A 0.059% + 2.8 m A 300 A
10.0000 A
3
500 A 0.089% + 5.9 m A 300 A
TEMPERATURE COEFFICIENT (0 18 C & 28 50 C): –(0.15 ∞ accuracy specification)/ C.
MAX. OUTPUT POWER: 110W (four quadrant source or sink operation, DC mode)
2
. 1100W (four quadrant source or sink operation, PULSE mode)
3
.
SOURCE/SINK LIMITS: –1.05A @ 105V, –3.15A @ 2 1 V, –10.5A @ 105V 2.5ms pulse.
CURRENT REGULATION: Line: 0.01% of range. Load: 0.01% of range + 100pA.
V O LTAGE LIMIT:Bipolar volt age limit (compliance) set with single value. Min. 0.1% of range.
OVERSHOOT:<0.1% typical (1mA step, R
L = 10k , 20V range).
