Specifications A-7
Additional Source Specifications
TRANSIENT RESPONSE TIME: 30 s typical for the output to recover to it s spec. following a step change in load. Resistive load.
COMMAND PROCESSING TIME: Maximum time required for the output to begin to change following the receipt of :SOURce:VOLTage|CURRent
<nrf> command.Autorange On: 10ms. Autorange Off: 7ms.
OUTPUT SETTLING TIME: Time required to reach 0.1% of final value af ter command is processed. 100 s typical. Resistive load. 10 A to 100mA
range, 1V step.
OUTPUT SLEW RATE: 0.25V/ s –30%, 100V range, 100mA compliance. 0.08V/ s –30%, 20V range, 100mA compliance.
COMMON MODE VOLTAGE: 250VDC.
REMOTE SENSE: Up to 1V drop per load lead.
COMPLIANCE ACCURACY:For Source mode, add 0.1% of range to base specification. For Sink mode, 10 A to 100mA range, accuracy is –(0.5%
+ of fset
*
3). For Sink mode, 1A and 3A ranges, accuracy is –(1.5% + offset
*
3).
OVER TEMPERATURE PROTECTION: Internally sensed temperature overload put s unit in st andby mode.
RANGE CHANGE OVERSHOOT:Overshoot into a fully resistive 100k load, 10Hz to 1MHz BW, adjacent ranges: (100mV) typical, except 20V/100V
range boundary.
MINIMUM COMPLIANCE VALUE: 0.1% of range.
CONTACT CHECK: 2ž 15ž 50ž
No contact check failure <1.00 <13.5 <47.5
Always contact check failure >3.00 >16.5 >52.5
Additional Pulse Mode Source Specifications
MAXIMUM DUTY CYCLE: 8%, hardware limited, 10A range only. All other ranges 84%.
MAXIMUM PULSE WIDTH: 5ms from 90% rising to 90% falling edge, 2.5ms 10A range.
MINIMUM PULSE WIDTH: 150 s, with 0.004 PLC measurement.
MINIMUM PULSE RESOLUTION: 10 s typical, 20 s max., limited by system jitter.
SOURCE ACCURACY:Determined by settling time and source range specifications.
OUTPUT SETTLING TIME, 0.1%:
800 s typ., source I = 10A into 10 , limited by volt age slew rate.
500 s typ., source I = 10A into 1 , limited by volt age slew rate.
OUTPUT SLEW RATE:Voltage (10 load): 0.25V/ s –30% on 100V range
0.08V/ s –30% on 20V range, 10A range.
Current (0 load): 0.25A/ s –30% on 100V range
0.08A/ s –30% on 20V range, 10A range.
1
S pecifications valid for continuous output current s below 105mA. For operating above 105mA on the 1A range for >1 minute, derate accuracy 10%/100mA
above 105mA. For operating above 105mA on the 3A range for >1 minute, derate accuracy 10%/300mA above 105mA.
2
Full power source operation regardless of load to 30 C. Above 30 C and/or power sink operation, refer to the Power Equations section of the User s Manual.
For power line volt ages less than 95V, limit max. current to 0.85A on 1A range and 2.5A on 3A range.
3
1 0 A range only in pulse mode. Limited to 2.5ms pulse wid th maximum, 8% duty cycle maximum.
