A-8 Specifications
Measure Specifications
1, 2, 7
Voltage Measurement Accuracy (remote sense)
Max. Input Accuracy (23 C – 5 C)
Range Resolution Resist ance 1 Y ear, –(%rdg + volts)
200.000 m V 1 V >10 G 0.012% + 300 V
2.00000 V 10 V >10 G 0.012% + 300 V
20.0000 V 100 V >10 G 0.015% + 1 m V
100.000 V
7
500 V >10 G 0.015% + 5 m V
TEMPERATURE COEFFICIENT (0 18 C & 28 50 C):
–(0.15 ∞ accuracy specification)/ C.
Current Measurement Accuracy (local or remote sense)
Max. Voltage Accuracy (23 C – 5 C)
Range Resolution *Burden
3
1 Year, –(%rdg + a m p s)
10.0000 A 100 pA < 1mV 0.027% + 700 pA
100.000 A 1 nA < 1mV 0.025% + 6 nA
1.00000 m A 10 nA < 1mV 0.027% + 60 nA
10.0000 m A 100 nA < 1mV 0.035% + 600 nA
100.000 m A 1 A < 1mV 0.055% + 6 A
1.00000 A 10 A < 1mV 0.060% + 120 A
3.00000 A/ 30 A < 1mV 0.052% + 1.71 m A
10.0000 A
6
30 A < 1mV 0.082% + 1.71 m A
TEMPERATURE COEFFICIENT (0 18 C & 28 50 C):
–(0.1 ∞ accuracy specification)/ C.
Resist ance Measurement Accuracy (4 wire remote sense)
Source I Mode, Auto Ohms
Max. Default Normal Accuracy (23 C – 5 C) Enhanced Accuracy (23 C – 5 C)
5
Range Resolution Test Current 1 Y ear, –(%rdg + ohms) 1 Year, –(%rdg + ohms)
<0.20000
4
1 Source I ACC + Measure VACC Measure IACC + Measure VACC
2.00000 10 1 A 0.169% + 0.0003 0.129% + 0.0001
20.0000 100 100 m A 0.098% + 0.003 0.073% + 0.001
200.000 1 m 10 m A 0.077% + 0.03 0.053% + 0.01
2.00000 k 10 m 1 m A 0.066% + 0.3 0.045% + 0.1
20.0000 k 100 m 100 A 0.063% + 3 0.043% + 1
200.000 k 1 10 A 0.065% + 30 0.046% + 10
2.00000 M 10 10 A 0.068% + 100 0.049% + 50
20.0000 M 100 1 A 0.249% + 1 k 0.112% + 500
>20.0000 M
4
1 k Source I ACC + Measure VACC Measure I ACC + Measure VACC
TEMPERATURE COEFFICIENT (0 18 C & 28 50 C): –(0.15 ∞ accuracy specification)/ C.
SOURCE I MODE, MANUAL OHMS: Tot al uncert ainty = I source accuracy + V measure accuracy (4-wire remote sense).
SOURCE V MODE: Tot al uncert ainty = V source accuracy + I measure accuracy (4-wire remote sense).
6-WIRE OHMS MODE: Available using active ohms guard and guard sense. Max. Guard Output Current: 50 mA (except 1A and 3A
ranges). Accuracy is load dependent. Refer to manual for calculation formula.
GUARD OUTPUT IMPEDANCE: 0.1 in ohms mode.
1
S peed = Normal (1 PLC). For 0.1 PLC, add 0.005% of range to offset specifications, except 200mV, 1A ranges, add 0.05%; 3A/10A range, add 1.5mA. For
0.01 PLC, add 0.05% of range to offset specifications, except 200mV, 1A ranges, add 0.5%; 3A/10A range, add 15mA.
2
Accuracies apply to 2- or 4-wire mode when properly zeroed.
3
4-wire mode.
4
Manual ohms mode only.
5
Source readback enabled, offset compensation ON.
6
1 0 A range only in pulse mode.
7
In pulse mode, limited to 0.1 PLC measurement.
Section A (pgs 6-10).qxd 11/7/2005 1:35 PM Page 4
