A-10 Specifications
General
NOISE REJECTION:
NPLC NMRR CMRR
Fast 0.01 80 dB
Medium 0.1 80 dB
Normal 1 60 dB 120 dB
1
1
Except lowest current range = 90dB.
LOAD IMPEDANCE: Stable into 20,000pF typical.
COMMON MODE VOLTAGE: 250VDC, externally limited to 3.15A max.
COMMON MODE ISOLATION: >10
9
, <1000pF.
OVERRANGE: 105% of range, source and measure.
MAX. VOLTAGE DROP BETWEEN INPUT/OUTPUT AND SENSE TERMINALS: 5 volts.
SOURCE/MEASURE TERMINAL R ATING: Inst allation cetegory I.
MAX. SENSE LEAD RESISTANCE: 1M for rated accuracy.
SENSE INPUT IMPEDANCE: >10
10
.
GUARD OFFSET VOLTAGE: 500 V, typical.
SOURCE OUTPUT MODES: Pulse Memory List (mixed function)
Fixed DC level S tair (linear and log)
SOURCE MEMORY LIST:100 point s max.
MEMORY BUFFER: 5,000 readings @ 5H digit s (two 2,500 point buf fers). Includes selected measured value(s) and time st amp. Lithium battery
backup (3 yr+ battery life).
PROGRAMMABILITY:IEEE-488 (SCPI-1996.0), RS-232, 5 user definable power-up states plus factory default and *RST.
DIGITAL INTERFACE:
Safety Interlock: Active low input.
Handler Interface: S tart of test, end of test, 3 category bit s. +5V @ 300mA supply.
Digit al I/O: 1 trigger input, 4 TTL/Relay Drive output s (33V @ 500mA sink, diode clamped).
POWER SUPPLY:100V to 240V rms, 50 60Hz, 250VA.
COOLING: Forced air, variable speed.
W ARRANTY:1 year.
EMC: Conforms with European Union Directive 89/336/EEC EN 61326.
SAFETY: Conforms with European Union Directive 73/23/EEC EN 61010-1.
VIBRATION: MIL-T-28800E Type III, Class 5.
W ARM-UP: 1 hour to rated accuracies.
DIMENSIONS: 89mm high 213mm wide 370mm deep (3
1
2 in 8
3
8 in 14
9
16 in). Bench Configuration (with handle & feet): 104mm high
238mm wide 370mm deep (4
1
8 in 9
3
8 in 14
9
16 in).
WEIGHT:4.1kg (9.0 lbs).
ENVIRONMENT:Operating: 0 50 C, 70% R.H. up to 35 C. Derate 3% R.H./ C, 35 50 C. S torage: 25 C to 65 C.
S pecifications subject to change without notice.
