Keithley 2430 User Manual

6-6 Replaceable Parts
Q228, 247, 248, 520, 601 TRANS, PNP, MMBT3906L TG-244
Q242, Q243 TRANS, N-CHAN MOSFET, TN254ON8 TG-274
Q249, Q528 TRANS, NPN SILICON, BC846BL TG-278
Q250, Q529 TRANS, PNP, BC856BL TG-287
Q401, 404, 405, 410, 411, 420, 502,
540, 541
TRANS, N-MOSFET, VN0605T TG-243
Q402, Q409, Q259 TRANS, N-CHAN DMOS FET, TN2504N8 TG-261
Q403, Q406, Q407, Q408 TRANS, N-CHAN JFET, SST109 TG-266
Q412, Q414 TRANS, N-MEGAFET, RFD14N05LSM TG-267
Q415, Q416 TRANSISTOR TG-377
Q417, Q419 N CHANNEL MEGAFET TG-339
Q230, Q418, Q542 TRANS, P-CHAN, MOSFET, TP0610T TG-259
Q500, Q503 TRANSISTOR TG-372
Q504, Q514, Q516, Q518 N CHANNEL POWER MOSFET TG-349
Q507, Q521, Q523, Q525 P CHANNEL POWER MOSFET TG-348
Q526, Q527, Q530, Q531 TRANS, N CHANNEL MOSFET,
SI9410DY
TG-302
Q532, Q536 TRANS, N-CHANNEL FET, IRF630 TG-214
Q533, Q539 TRANS, P-CHANNEL 200V FET, IRF9630 TG-215
Q535, 537, 538, 600 TRANS, NPN, MMBT3904 TG-238
Q602-607 TRANS, N-MOSFET, VN0605T TG-243
R117-128, 133-136, 141-144 RES, 10K, 5%, 250MW, METAL FILM R-376-10K
R129, 155, 211, 224-229, 234-237,
244-247, 281
RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R137-140, R145-149, R713, R714 RES, 10K, 5%, 250MW, METAL FILM R-376-10K
R150, 151, 389, 390, 431-434, 451,
520, 531, 536
RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R152 RES, 4.99K, 0.1%, 0.125W, THIN FILM R-456-4.99K
R153, 154, 240, 243, 248, 251, 253,
254, 257, 258
RES, 4.99K, 1%, 100MW, THICK FILM R-418-4.99K
R200, R201, R203, R232, R238 RESISTOR NETWORK, 10K-10K TF-236
Table 6-1 (cont.)
Analog board parts list
Circuit designation Description
Keithley
Part No.
