Replaceable Parts 6-7
R202, 204, 252, 255, 256, 259, 260,
263, 264, 267
RES, 100K, 1%, 100MW, THICK FILM R-418-100K
R205, 310, 485, 552, 595, 598 RES, 0.0499, 1%, 100MW, THICK FILM R-418-.0499
R207 RES, 20K, 0.1%, 0.125W, THIN FILM R-456-20K
R208, R210 RES, 768, 1%, 100MW, THICK FILM R-418-768
R209, 268, 269, 270, 271, 658 RES, 1M, 1%, 100MW, THICK FILM R-418-1M
R212 RES, 332, 1%, 100MW, THICK FILM R-418-332
R213 RES NET 5K, 0.1%, 668A TF-243-5K
R216, 221, 223, 274, 275, 276, 277,
278, 279
RES, 20K, 1%, 100MW, THICK FILM R-418-20K
R217 RES, 121K, 1%, 100MW, THICK FILM R-418-121K
R218 RES, 80.6K, 1%, 100MW, THICK FILM R-418-80.6K
R219, 220, 222, 230, 231, 373, 374,
616, 700, 701
RES, 49.9K, 1%, 100MW, THICK FILM R-418-49.9K
R241, R242, R249, R250, R653,
R664
RES, 140K, 1%, 100MW, THICK FILM R-418-140K
R261, 262, 265, 266, 311, 312, 313,
314, 315, 316
RES, 4.99K, 1%, 100MW, THICK FILM R-418-4.99K
R272, 273, 347, 348, 511, 512 RES, 249K, 1%, 100MW, THICK FILM R-418-249K
R280 RES, 4.02K, 1%, 100MW, THICK FILM R-418-4.02K
R282, 284-286, 288, 301, 438, 439,
592, 617, 622
RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R283, 287, 297, 299, 349, 350, 351,
352, 457, 461
RES, 30.1K, 1%, 100MW, THICK FILM R-418-30.1K
R289, R303, R681, R684 RES, 20K, 0.1%, 0.125W, THIN FILM R-456-20K
R290, 309, 336, 340, 343, 344, 353,
355, 356, 359
RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R291, R293 RES, 42.7K, 0.1%, 0.125W, THIN FILM R-456-42.7K
R292, 338, 527, 528, 533, 535, 544,
546, 547, 588
RES, 100K, 1%, 100MW, THICK FILM R-418-100K
R294, R295, R296 RES, 100K, 0.1%, 0.125W, THIN FILM R-456-100K
R298, R300 RES, 150K, 1%, 100MW, THICK FILM R-418-150K
R302 RES, 0.0499, 1%, 100MW, THICK FILM R-418-.0499
Table 6-1 (cont.)
Analog board parts list
Circuit designation Description
Keithley
Part No.
To Next Page
