Keithley 2430 User Manual

6-8 Replaceable Parts
R304, R305, R306, R548 RES, 33, 5%, 250MW, METAL FILM R-376-33
R307, R413, R652, R665 RES, 357, 1%, 100MW, THICK FILM R-418-357
R308, 379-387, 391, 392 RES, 475, 1%, 100MW, THICK FILM R-418-475
R317, 334, 335, 337, 339, 357, 366,
367, 424, 425
RES, 4.99K, 1%, 100MW, THICK FILM R-418-4.99K
R318, R563 RES, 15k, 1%, 100MW, THICK FILM R-418-15K
R332, 423, 430, 604, 606 RES, 499, 1%, 100MW, THICK FILM R-418-499
R341, R342, R697, R698 RES, 13K, 1%, 100MW, THICK FILM R-418-13K
R345, 364, 370, 371, 372, 402, 403,
404, 416, 417
RES, 100K, 1%, 100MW, THICK FILM R-418-100K
R346 RES, 402K, 1%, 100MW, THICK FILM R-418-402K
R354, R437 RES, 560K, 5%, 250MW, METAL FILM R-376-560K
R358, 482, 484, 487 RES, 6.04K, 1%, 100MW, THICK FILM R-418-6.04K
R361, 362, 365, 369, 418, 419, 420,
421, 456, 458
RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R363 THICK FILM TF-274
R368 RES, 332, 1%, 100MW, THICK FILM R-418-332
R375, R376, R576, R578 RES, 10, 10%, 100MW, THICK FILM R-418-10
R388, 393-399, 411, 412, 699 RES, 357, 1%, 100MW, THICK FILM R-418-357
R422 RES, 4.7K, 5%, 250MW, METAL FILM R-376-4.7K
R426, 429, 601, 603, 605, 608, 626,
702, 703
RES, 4.99K, 1%, 100MW, THICK FILM R-418-4.99K
R435, 504, 590, 673, 688, 689, 715,
716
RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R436 RES, 499, 1%, 100MW, THICK FILM R-418-499
R450 RES, 200K, 0.1%, 1/10W, METAL FILM R-263-200K
R452 RES, 21.93K, 0.1%, 1/10W, METAL FILM R-263-21.93K
R453 RES, 1.82K, 0.1%, 1/10W, METAL FILM R-263-1.82K
R454, R455, R467, R468, R469,
R470, R471
RES, 100, 0.1%, 1/10W, METAL FILM R-263-100
R459, 488, 500, 515, 560, 561, 562,
600
RES, 100K, 1%, 100MW, THICK FILM R-418-100K
Table 6-1 (cont.)
Analog board parts list
Circuit designation Description
Keithley
Part No.
