Keithley 2430 User Manual

Replaceable Parts 6-9
R460, 462, 466, 472, 478, 481, 489,
502, 510, 558
RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R463, 473, 479 RES, 30.1K, 1%, 100MW, THICK FILM R-418-30.1K
R474 RES, 0.2 5%, 2W R-473-.2
R483, R691, R695 RES, 2K, 1%, 100MW, THICK FILM R-418-2K
R490 RES, 205, 0.1%, 1/10W, METAL FILM R-263-205
R501, R514, R529 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R503, R545, R587 RES, 15k, 1%, 100MW, THICK FILM R-418-15K
R505 RES, 13K, 1%, 100MW, THICK FILM R-418-13K
R506, R507 RES, 150K, 5%, 250MW, METAL FILM R-376-150K
R508, R509 RES, 150K, 5%, 250MW, METAL FILM R-376-150K
R516, R523 RES, 4.02K, 1%, 100MW, THICK FILM R-418-4.02K
R517, R524, R564, R565, R566,
R567
RES, 12.1, 1%, 125MW, METAL FILM R-391-12.1
R521 RES, 2M, 1%, 100MW, THICK FILM R-418-2M
R525, R526 RES, 1.21K, 1%, 100MW, THICK FILM R-418-1.21K
R530, R532, R534, R537, R559,
R712
RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R538, 539, 540, 541, 542, 543, 568,
569
RES, 0.5, 5%, 1W, METAL R-444-.5
R553, R554 RES, 75K, 1%, 100MW, THICK FILM R-418-75K
R570, 571, 573, 581, 705 RES, 249, 1%, 100MW, THICK FILM R-418-249
R572, 574, 580, 582 RES, 200K, 1%, 100MW, THICK FILM R-418-200K
R575, R579, R614, R615 RES, 2.21K, 1%, 100MW, THICK FILM R-418-2.21K
R583, 584, 585, 586 RES, 10, 5%, 125MW, METAL FILM R-375-10
R589 RES, 249K, 1%, 100MW, THICK FILM R-418-249K
R602, R607 RES, 150, 5%, 250MW, METAL FILM R-376-150
R609 RES NET TF-245
R610 RES, 1.28M, 0.1%, 1/8W, METAL FILM R-176-1.28M
R611, R621 RES, 475, 1%, 100MW, THICK FILM R-418-475
R612 RES, 5.11K, 1%, 100MW, THICK FILM R-418-5.11K
R613, 624, 659, 660 RES, 100, 1%, 100MW, THICK FILM R-418-100
Table 6-1 (cont.)
Analog board parts list
Circuit designation Description
Keithley
Part No.
