Keithley 2430 User Manual

6-10 Replaceable Parts
R618 RES, 34K, 1%, 100MW, THICK FILM R-418-34K
R619 RES, 4.75K, 1%, 100MW, THICK FILM R-418-4.75K
R620 RES, 82.5, 1%, 100MW, THICK FILM R-418-82.5
R623 RES, 10, 10%, 100MW, THICK FILM R-418-10
R650, R651 RES NET, 9K-1K, MICRO DIVIDER TF-246-2
R130, 654, 655, 668, 669, 687 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R656 RES, 6.04K, 0.1%, 0.125W, THIN FILM R-456-6.04K
R657, R692, R696 RES, 1M, 1%, 100MW, THICK FILM R-418-1M
R666 RES NET, 3K, 12K, 0.1%, 100MW,
THINFILM
TF-237-2
R670 THICK FILM TF-273-4
R672 RES, 2M, 1%, 100MW, THICK FILM R-418-2M
R675, 704, 706, 707, 708, 709 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R682, R685 RES, 42.7K, 0.1%, 0.125W, THIN FILM R-456-42.7K
R683, R686 RES, 7.32K, 0.1%, 0.125MW, THIN FILM R-456-7.32K
R690, R694 RES, 100K, 5%, 250MW, METAL FILM R-376-100K
R710 RES, 0.065, 1%, 3W R-474-.065
R717, R718 RES, 10, 5%, 250MW, METAL FILM R-376-10
R719 RES, 100, 5%, 125MW, METAL FILM R-375-100
R721 RES, 2K, 1%, 100MW, THICK FILM R-418-2K
RT200 POLYSWITCH, PTC RESISTOR RT-17
RT500 THERMISTER, PD=7MW/DEG C, 1500V,
613.74K
RT-8
TP200-215, 218-225, 227, 228,
230-235
SURFACE MOUNT PCB TEST POINT CS-1026
TP500-505, 507, 508, 510 SURFACE MOUNT PCB TEST POINT CS-1026
U201, U238 IC, CMOS ANA SWITCH SPST
MAX326CSE
IC-909
U202, U203, U650 IC, OP AMP LT1112 IC-1048
U204, U229 IC, 8-CHAN ANA MULTIPLEXER,
DG408DY
IC-844
U205, U407 IC, HEX INVERTERS, 74HCT04 IC-880
Table 6-1 (cont.)
Analog board parts list
Circuit designation Description
Keithley
Part No.
