Introduction Test
These steps confirm basic functionality of your Model
2651A. Please turn instrument power OFF now.
When you finish making measurements, turn the output off by
pressing the OUTPUT ON/OFF
control. The output indicator
LED turns off.
Observe the measured voltage on the main area of front panel
display. The readings should be very close to the 20 V source value.
The examples in the Model 2651A User’s Manual are designed to
demonstrate increasing levels of Model 2651A functionality. We
strongly recommend first-time users complete the examples in the
manual.
Step 5: Observe measurements
Step 6: Turn output off
2. Press the AUTO key as many times as needed to select
the AUTO range function. When AUTO is selected, the Model
2651A automatically selects the best range for the measured
value. You will briefly see the display shown below, and then the
main display screen reappears.
Turn the output on by pressing the OUTPUT ON/OFF
control. The ON/OFF indicator LED lights and measurements
begin.
AUTO
To Next Page
