Keithley 486 Quick Reference Guide

V-Source Operation
1.
While in standby, connect the V-Source as shown
in Figure 4.
2.
Use the rotary knob, and the 4 and b keys to set
the desired voltage range and level.
3.
Select the appropriate l-limit (25pA or 2.5mA).
4. Press Operate.
5.
To disable the V-Source, again press OPERATE.
3anana r;
‘lug Cables
HI r
--
7
-%---I
Safety
1 Shield
Model 487
Figure 4. Basic V-Source Connections
