B-4 SCPI Tables (Abridged) Model 6220/6221 User’s Manual
Return to Appendix B tables
Table B-6
Source command summary
Command Description Default
SOUR Current source output commands:
:CLE Clearing the current source:
[:IMM] Set output to zero and then turn the output off.
:CURR Current source:
[:AMPL] <n> Set current source output (amps): -105e-3 to 105e-3 0.0
:RANG <n> Select a fixed source range: -105e-3 to 105e-3 100e-3
:AUTO <b> Enable or disable source auto range. OFF
:COMP <NRf> Set voltage compliance (volts): 0.1 to 105 10
:FILT <b> Enable or disable analog filter.
:STAR <n> Set start current (amps): -105e-3 to 105e-3 0
:STOP <n> Set stop current (amps): -105e-3 to 105e-3 100e-3
:STEP <n> Set step current (amps): 1e-13 to 105e-3 1e-2
:CENT <n> Set center current (amps): -105e-3 to 105e-3 0
:SPAN <n> Set span current (amps): 2e-13 to 210e-3 100e-3
:DEL <n> Set source delay (seconds): 1e-3 to 999999.999 1
:SWE Source sweep operation:
:SPAC <name> Select sweep type: LIN, LOG or LIST LIN
:POIN <n> Set sweep points: 1 to 65535 11
:RANG <name> Select sweep ranging: AUTO, BEST or FIX BEST
:COUN <NRf> Set sweep count: 1 to 9999 or INFinity 1
:CAB <b> Enable to abort sweep on compliance: ON or OFF OFF
:ARM Arm the sweep.
:ABOR Abort sweep or delta test immediately.
:LIST Custom sweep operation:
:CURR <NRf>
[,<NRf>, ...<NRf>]
Define list of currents (amps): -105e-3 to 105e-3
:APP <NRf>
[,<NRf>, ...<NRf>]
Add current points to existing list: -105e-3 to 105e-3
:POIN? Query number of current list points.
:DEL <NRf>
[,<NRf>, ...<NRf>]
Define list of delay values (secs): 1e-3 to 999999.999 1
:APP <NRf>
[,<NRf>, ...<NRf>]
Add delay values to existing list.
