Model 6220/6221 User’s Manual SCPI Tables (Abridged) B-5
Return to Appendix B tables
:COMPliance <NRf>
[,<NRf>, ...<NRf>]
Define list of compliance values (volts): 1e-3 to 105
:APP <NRf>
[,<NRf>, ...<NRf>]
Add compliance values to existing list: 1e-3 to 105
:DELta Delta operation:
:NVPR? Query connection to 2182/2182A: 1 = yes, 0 = no
:HIGH <NRf> Set high source value (amps): 0 to 105e-3 1e3
:LOW <NRf> Set low source value (amps): 0 to -105e-3 -1e3
:DEL <NRf> Set Delta delay (seconds): 1e-3 to 9999.999 2e-3
:COUN <NRf> Set number of cycles to run: 1 to 65536 or INFinity. INF
:CAB <b> Enable to abort test on compliance: ON or OFF OFF
:CSW <b> Enable cold switching mode: ON or OFF. OFF
:ARM Arm Delta.
:PDEL Pulse Delta operation:
:NVPR? Query connection to 2182A: 1 = yes, 0 = no
:HIGH <NRf> Set high pulse value (amps): -105e-3 to 105e-3 1e3
:LOW <NRf> Set low pulse value (amps): -105e-3 to 105e-3 0
:WIDT <NRf> Set pulse width (seconds): 50e-6 to 12e-3 110e-6
:SDEL <NRf> Set source delay (seconds): 16e-6 to 11.966e-3 16e-6
:COUN <NRf> Set number of readings to perform: 1 to 65636 or INF INF
:RANG <NRf> Select fixed pulse source range: BEST or FIX BEST
:INT <NRf> Set interval (in PLCs) for each pulse cycle: 5 to 999999 5
:SWE <b> Enable or disable Sweep output mode. OFF
:LME <NRf> Set number of low measurement per cycle: 1 or 2 2
:ARM Arm Pulse Delta.
:DCON Differential Conductance operation:
:NVPR? Query connection to 2182/2182A: 1 = yes, 0 = no
:STAR <NRf> Set start value (amps): -105e-3 to 105e-3. -10e-6
:STEP <NRf> Set step size (amps): 0 to 105e-3. 1e-6
:STOP <NRf> Set stop value (amps): -105e-3 to 105e-3. +10e-6
:DELT <NRf> Set delta value (amps): 0 to 105e-3. 1e-6
:DEL <NRf> Set delay (seconds): 1e-3 to 9999.999. 2e-3
:CAB <b> Enable to abort test on compliance: ON or OFF OFF
:ARM Arm Differential Conductance.
Table B-6 (cont.)
Source command summary
Command Description Default
