B-6 SCPI Tables (Abridged) Model 6220/6221 User’s Manual
Return to Appendix B tables
:WAVE Wave function operation:
:FUNC <name> Select wave function: SIN, SQU, RAMP or ARBX (X = 0 to 4). SIN
:DCYC <NRf> Set duty cycle (in %): 0 to 100 50
:AMPL <NRf> Set amplitude (amps peak): 2e-12 to 105e-3. 1e-3
:FREQ <NRf> Set frequency (Hz): 1e-3 to 1e5 1e3
:OFFS <NRf> Set offset (amps): -105e-3 to 105e-3 0
:PMAR Phase marker:
[:LEV] <NRf> Set marker phase (in degrees): 0 to 360 180
:OLIN <NRf> Set phase marker trigger line: 1 to 6 3
:STAT <b> Enable or disable phase marker. OFF
:ARB Arbitrary waveforms:
:DATA <NRf>
[,<NRf>, ...<NRf>]
Define arbitrary data points: -1 to +1 (100 points maximum).
:DATA? Query the points in the arbitrary waveform.
:APP <NRf>
[,<NRf>, ...<NRf>]
Append arbitrary data points: -1 to +1 (100 points max. per
instance of command).
:POIN? Query number of points in the waveform.
:COPY <NRf> Copy arbitrary points to NVRAM: 1 to 4
:RANG <name> Select source ranging mode: BEST or FIX BEST
:DUR Waveform duration:
:TIME <NRf> Set waveform time duration (seconds): 100e-9 to 999999.999
or INF.
INF
:CYCL <NRf> Set waveform duration in cycles: 1e-3 to 99999999900 or INF INF
:ARM Arm waveform function.
:INIT Start waveform output.
:ABOR Abort waveform output.
:EXTR Waveform external trigger commands: *
[:ENAB] <b> Enables/disables mode to externally trigger the
waveform generator: <b> = ON or OFF.
OFF
:ILIN <NRf> Specify trigger link input trigger line:
<NRf> = 0 (none) or 1 to 6.
0
:IGN <b> Sets whether or not to restart waveform upon
retriggering: <b> = ON or OFF.
OFF
:IVAL <NRf> Sets inactive value to output before/after
waveform: <NRf> = -1 to +1.
0.00
* Available with firmware revision A03 and later.
Table B-6 (cont.)
Source command summary
Command Description Default
