Keithley S530 Option Manual

Section
3: Software Reference S530 Parametric Test Systems Frequency Analysis Option
Manual
3-2 S530-923-01 Rev. A / January 2014
ring_lcc
Purpose: This algorithm detects frequencies of the top five amplitudes that are longer than a given
level (default 0.5 mV)(see next figure). Otherwise, zero will be the output if the amplitude
threshold is not met. The output frequencies are sorted in descending order of amplitude,
that is, from the highest amplitude to the lowest amplitude.
Parameters:
Inputs Type Description
vcc_pin int
Pin number of V
cc
pin
vccb_pin int
Pin number of V
ccb
pin
vss_pin int
Pin number of V
ss
pin
out_pin
int
Pin number of signal output pin
vcc
double
Voltage of V
cc
vccb double
Voltage of V
ccb
stages int Number of stages (to the signal output)
min_freq double
Beginning frequency of the scan
spectrum
max_freq
double
Ending frequency of the scan spectrum
step_freq
double
Resolution (step frequency) of the scan
min_level double
Minimum amplitude; the peak detected
must be higher than this level
size int Size of output array (default = 5)
size1
int
Size of output array (default = 5)
When using the ring_Icc algorithm, size must equal size 1.
Outputs Type Description
Tdelay
double
Calculated device delay time:
Icc
double
Measured current of pin V
cc
in amps
Iccb
double
Measured current of pin V
ccb
in amps
Frequency
double
Measured frequency array (sorted) in Hz
amplitude
double
Amplitude of the associated frequency. If output is 0, it cannot find signal
stronger than min_level in dB
