Keithley S530 Option Manual

S530 Parametric Test Systems
Frequency Analysis Option Manual Section 2:
Basic Operations
S530-923-01 Rev. A / January 2014 2-3
Create a KITT macro (S530)
The following code creates a KITT macro (S530) that you can use to make a scope card
measurement:
double vcc = 5.0
conpin(SMU1, vcc_pin, vccb_pin, 0)
conpin(vss_pin,GND, 0)
conpin(SCP1A, out_pin, 0)
forcev(SMU1, vcc)
status_1 = freq_init()
status_2 = freq_setup(0e6, 15e6, 1e6)
status_3 = freq_measure(frequency,level)
