5-8 Sweep Operation Series 2600 System SourceMeters Reference Manual
2600S-901-01 Rev. A / May 2006 Return to Section 5 topics
Sweep measurement storage
When sweeps are run, measurements are automatically stored in non-volatile
memory Buffer 1 for later recall. Sweep data can be recalled as follows:
• Front panel: Press the RECALL key, select the channel and Buffer 1, then
choose reading numbers to display with the Rotary Knob or cursor keys.
• Remote: Use the printbuffer command to request buffer readings from
smua.nvbuffer1 (channel A) or smub.nvbuffer1 (channel B).
See Section 7 for details on recalling data from the buffer.
Sweep functions
Functions to perform staircase, pulse, and custom sweeps are discussed below.
See
Section 13 of this manual for details on using factory scripts.
NOTE Visit www.keithley.com for additional available user
scripts for various tests.
